75W Ultra-Slim 12V LED Power Supply – Efficient Constant Voltage Driver for LED Strips

Categories IP20 LED Power Supply
Brand Name: ANENpower
Model Number: APL075S
Certification: UL/CUL, FCC, CE, GS, TUV, CB, RCM, SAA, PSE, KC, UKCA
Place of Origin: Shenzhen
MOQ: 500pcs
Price: Please contact our Sales
Payment Terms: 50% deposit, 50% before dispatch
Supply Ability: 500,000.00pcs/month
Delivery Time: 18~25 working days after receiving the deposit
Packaging Details: PE bag / White box / Custom made
Power: 75W max.
Input: 90-265V AC
Output Voltage: 12V/ 24V/ 36V /48V
Output Current: 6.25A/ 3125mA/ 2083mA/ 1562mA
Dimension(LxWxH): 184x63x22mm
Voltage Tolerance: ±5%
Riple(P-P): <1%
Efficiency: ≥90%
Applicant: Cabinet lights, LED strips, LED indoor lighting, LED decorative lighting, LED building lighting
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

75W Ultra-Slim 12V LED Power Supply – Efficient Constant Voltage Driver for LED Strips

75W Ultra-Slim 12V LED Power Supply – Efficient Constant Voltage Driver for LED Strips


Power your 12V LED strips reliably with this 75W ultra-slim constant voltage driver. Designed for high efficiency and stable output, it delivers a clean, flicker-free 12V supply—perfect for long runs of high-density LED tape in kitchens, retail displays, cove lighting, and more. Its exceptionally thin profile allows for discreet installation in tight spaces, while built-in protections ensure safe, maintenance-free operation. Ideal for both residential and commercial projects where performance and space-saving design matter.


- Universal Input: 90-265V AC 50/60Hz
- RoHS Compliance
- EMI Standard EN55015
- Safety Standard: EN61347-1, EN61347-2-13, UL8750
- Inrush current<65A AC230V/50Hz - High efficiency & low power consumption
- Short Circuit, Over Current and Over Voltage Protection
- Over temperature protection
- 100% full load burn-in test
- Auto restart after remove of fault conditions
- IP20 protection rating


MODEL DETAIL SPEC.

APL075S

-1206250

APL075S

-2403125

APL075S

-3602083

APL075S

-4801562

INPUTInput Voltage:100-240VAC/ 200-240VAC
Input Frequency:50-60Hz
Inrush Current:65 Amps max. at 230VAC/50Hz,full load
AC Current:0.17A/230VAC
Leakage Current:0.25mA/240VAC
Efficiency:88%88%88%88%
OUTPUTDC Voltage:12V24V36V48V
Rated Current:6250mA3125mA2083mA1562mA
Rated Power:75W75W75W75W
Voltage Tolerance:±5.0%±5.0%±5.0%±5.0%
Ripple and Noise:120mVp-p240mVp-p360mVp-p480mVp-p
Line Regulation:±3%
Load Regulation:±5%
Setup, Rise, Hold Up time:1s, 10ms/60ms 230VAC 1000ms, 1ms/25ms 115VAC at full load
ENVIRONMENTALOperating Temperature:-20 ~ +50 (Refer to "Derating Curve")
Storage Temp:-40 ~ 85
Storage Humidity:20 ~ 95% RH
Working Humidity:20 ~ 95% RH non-condensing
PROTECTIONOver Load:Above 105%-130% rated output power
Protection type: Hiccup mode, recovers automatically after fault condition is removed
Over Voltage:12V:13.8 ~ 16.2V 24V:27.6 ~ 32.4V 36V:41.4~48.6V 48V:55.2~64.8V
Protection type: Shut down o/p voltage, re-power on to recover
Over Temperature:Shut down o/p voltage, re-power on to recover
SAFETY & EMCSafety Regulations:EN61347-2-13:2014+A1:2017,EN61347-1:2015;EN62493:2015
Withstand Voltage:I/P-O/P:3750KVAC
HarmonicEN61000-3-2 Class C EN61000-3-3
EMI:Compliance to EN55015
EMS:compliance to 61547:2009
OTHERMTBF:200,000 Hours Minimum at Full Load at 25 Ambient
Size:184x63x22mm
Weight:200g / pcs
Packaging:100PCS/CTN,37.5*28.5*24cm

Quality 75W Ultra-Slim 12V LED Power Supply – Efficient Constant Voltage Driver for LED Strips wholesale
