| Categories | High Power Mosfet |
|---|---|
| Brand Name: | UCHI |
| Model Number: | SGM05HB1AM |
| Certification: | Completed |
| Place of Origin: | Dongguan China |
| MOQ: | 1000PCS |
| Price: | Negotiable |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 5000pcs |
| Delivery Time: | 3weeks |
| Packaging Details: | Standard |
| Peak Pulse Current (tP = 8/20μs): | 30A |
| ESD IEC 61000-4-2 (Air): | ±30kV |
| ESD IEC 61000-4-2 (Contact): | ±30kV |
| Operating Temperature Range: | -40 to +125℃ |
| Storage Temperature Range: | -55 to +150℃ |
| Lead Temperature (Soldering, 10s): | +260℃ |
| Company Info. |
| Guangdong Uchi Electronics Co.,Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
● Low Clamping Voltage
● Low Leakage
● Small Package: UTDFN-1×0.6-2AL
● Protection for the Following IEC Standards:IEC 61000-4-2 Level 4:
±30kV Contact DischargeIEC 61000-4-5 (Lightning) 30A (8/20μs)
● These Devices are Pb-Free, Halogen Free/BFRFree and are RoHS
Compliant
| Channel | Part Number | Configuration | VRWM Max (V) | IPPM Max (A) | CIN Typ (pF) | Packag | Features |
|---|---|---|---|---|---|---|---|
| 1 | SGM05CB1A4 | Bidirectional | 5 | 4 | 2.7 | UTDFN-1×0.6-2L,XTDFN-0.6×0.3-2L | Low Capacitance, 1-Channel ESD Protection |
| 1 | SGM05CB1A7 | Bidirectional | 5 | 7 | 9 | X4DFN-0.63×0.33-2L | Low Capacitance, 1-Channel ESD Protection |
| 1 | SGM05CB1A8 | Bidirectional | 5 | 8.5 | 9.6 | UTDFN-1×0.6-2L | Low Capacitance, 1-Channel ESD Protection |
| 1 | SGM05FB1E2 | Bidirectional | 5 | 2.4 | 0.3 | UTDFN-1×0.6-2L,XTDFN-0.6×0.3-2L | Femto-Farad Capacitance, 1-Channel ESD Protection |
| 2 | SGM05FB2E2 | Bidirectional | 5 | 2.5 | 0.3 | UTDFN-1×0.6-3L | Femto-Farad Capacitance, 2-Channel ESD Protection |
| SGM05HB1AM | Bidirectional | 4.8/5.5 | 30 | 36 | UTDFN-1×0.6-2AL | 5V Bidirectional ESD and Surge Protection Device | |
| 1 | SGM05UB1B3 | Bidirectional | 5 | 4.2 | 0.5 | UTDFN-1×0.6-2L,XTDFN-0.6×0.3-2L | Ultra-Low Capacitance, 1-Channel ESD Protection |
| 1 | SGM12CB1A5 | Bidirectional | 12 | 5 | 1 | UTDFN-1×0.6-2L | Low Capacitance, 1-Channel ESD Protection |
| 1 | SGM12UB1D2 | Bidirectional | 12 | 2 | 0.35 | UTDFN-1×0.6-2L,XTDFN-0.6×0.3-2L | Ultra-Low Capacitance, 1-Channel ESD Protection |
| 1 | SGM15CB1A4 | Bidirectional | 15 | 4 | 1 | UTDFN-1×0.6-2L | Low Capacitance, 1-Channel ESD Protection |
| 1 | SGM15UB1E2 | Bidirectional | 15 | 2 | 0.35 | UTDFN-1×0.6-2L,XTDFN-0.6×0.3-2L | Ultra-Low Capacitance, 1-Channel ESD Protection |
|
