Cylinder-type High-temperature In-furnace Camera

Categories High Temperature Furnace Camera
Brand Name: KAIDUN
Model Number: KDG015
Place of Origin: China
MOQ: 1
Payment Terms: T/T
Supply Ability: 5000 units/year
Delivery Time: 5-8 week
Packaging Details: Wooden box packaging / cardboard box packaging
Visible Resolution: 2MP/4MP optional
Visible Focal Length: 4-20mm/3-10mm High-temperature Resistant Manual Lens
Operating Conditions: Temperature inside the furnace ≤ 1500°C
Dust Concentration in the Operating Environment: ≤ 200 mg/m3 (based on cement dust as the standard)
Power: DC12V/POE optional
Total Weight: ≤30kg
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Cylinder-type High-temperature In-furnace Camera

Cylinder-type High-temperature In-furnace Camera
Key Features
  • The KDG015 is a High-temperature Camera Equipped with an Air-cooled housing
  • The camera lens of this system equipment can be directly extended to the observation hole on the furnace wall to monitor the operation of workpieces inside the furnace, as well as the conditions of materials, flame shape,and other related situations.
Application Environment

Metallurgical & Steel Industry


Power Generation Industry


Petrochemical & Chemical Industry


Glass & Ceramic Industry


Waste Incineration & Environmental Protection

High-temperature resistant cameras are engineered to operate reliably in extreme thermal environments (typically -40°C to 1200°C, depending on models) where standard cameras fail due to overheating, component degradation, or structural damage.
Main Features
Material304 Stainless Steel + Local High-temperature Resistant Pot
Operating ConditionsTemperature inside the furnace ≤ 1500℃
Dust Concentration in
the Operating Environment
≤ 200 mg/m3 (based on cement dust as the standard)
VideoIP
Visible Resolution2MP/4MP etc
Visible Focal Length4-20mm/3-10mm High-Temperature Resistant Manual Lens
Cooling MethodAir Cooling
Comperssed Air Pressure0.2~0.4Mpa
Compressed Air Flow Rate0.3~0.7m³/min(0.7 m³/min at an air pressure of 0.4 MPa)
General FunctionAnti-flicker, Dual Stream, Rotation,Heartbeat, Mirroring, Password-protected Video Masking,Watermarking Technology,IP Address Filtering
Intelligent AlarmCross-line Detection; Region Intrusion Detection;Motion Detection; Dynamic Analysis Tampering Alarm;Network Cable Disconnection;IP Address Conflict; Unauthorized Access
VoltageDC12V/POE optional
Dimensions1318*Ø190mm
Weight≤30kg
MountingFlange-mounted etc
Dimensions
