| Categories | UV Laser Chiller |
|---|---|
| Brand Name: | TEYU |
| Model Number: | CWUP-20 |
| Certification: | CE, REACH and RoHS |
| Place of Origin: | China |
| MOQ: | Mail Inquiry |
| Price: | Mail Inquiry |
| Packaging Details: | Mail Inquiry |
| Delivery Time: | Mail Inquiry |
| Supply Ability: | Mail Inquiry |
| Model: | CWUP-20 |
| Machine Size: | 58 X29X52cm (L X W X H) |
| Warranty: | 2 years |
| Standard: | CE, REACH and RoHS |
| Company Info. |
| Guangzhou Hopoke CNC Equipment Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
TEYU circulating water chiller CWUP-20 is an active cooling portable water chiller that optimizes the operation of your ultrafast laser and UV laser system. The water temperature of this small laser chiller is PID controlled, delivering a particularly high degree of temperature stability of ±0.1°C and a cooling capacity of up to 1430W.
Portable industrial water chiller CWUP-20 supports RS485 communication to realize communication between the chiller and the laser system. Designed with multiple built-in alarm functions and an intelligent digital temperature controller. Easy-fill port is mounted on top while 4 caster wheels are easy for mobility.
Intelligent functions
* Low tank water level detecting
* Low water flow rate detecting
* Over water temperature detecting
* Heating of the coolant water at low ambient temperature
Self-check display
* 12 types of alarm codes
Easy routine maintenance
* Toolless maintenance of dustproof filter screen
* Quick-replaceable optional water filter
Communication function
* Equipped with RS485 Modbus RTU protocol
| Model | CWUP-20AI | CWUP-20BI |
| Voltage | AC 1P 220-240V | AC 1P 220~240V |
| Frequency | 50Hz | 60Hz |
| Current | 0.8~5.6A | 0.6~7.7A |
| Max. power consumption | 1.28kW | 1.37kW |
Compressor power | 0.59kW | 0.7kW |
| 0.8HP | 0.95HP | |
| 4879Btu/h | |
| 1.43kW | ||
| 1229Kcal/h | ||
| Refrigerant | R-410a | R-407c |
| Precision | ±0.1℃ | |
| Reducer | Capillary | |
| Pump power | 0.11kW | 0.09kW |
| Tank capacity | 6L | |
| Inlet and outlet | Rp1/2" | |
| Max. pump pressure | 2.5bar | |
| Max. pump flow | 19L/min | 15L/min |
| N.W | 25Kg | |
| G.W | 28Kg | |
| Dimension | 58X29X52cm (L X W X H) | |
| Package dimension | 65X36X56cm (L X W X H) | |
The working current can be different under different working conditions. The above information is for reference only. Please subject to the actual delivered product.
|
