| Categories | Fiber Optic Rotary Joint |
|---|---|
| Brand Name: | JINPAT |
| Model Number: | LPF0-01C |
| Certification: | ISO/CE/RoHS/UL |
| Place of Origin: | China |
| MOQ: | 10pcs |
| Price: | Negotiable |
| Payment Terms: | TT/CC/Paypal |
| Supply Ability: | 500 pieces a week |
| Delivery Time: | 2 weeks ARO |
| Packaging Details: | Standard/On Request |
| Number of Circuits: | 1 |
| Lead Size: | Lead Size |
| Wavelength range: | 650-1650nm （ customized） |
| Insertion loss: | ＜3db |
| Insertion loss ripple: | Single-Channel＜0.5dB |
| Return Loss: | ＞30 |
| Optional: | Single can be customized,housing material and driving connector are optional |
| Company Info. |
| JINPAT Electronics Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
LPFO optical slip rings are also known as fiber optic rotary joints, optical rotatory connector. The optical slip ring adopts optical fiber as media. It offers the best solution to transmit great capacity data and signals. The optical slip ring can be integrated with traditional electrical slip rings. The hybrid slip ring model is able to transmit power, signals and high speed data.
| Specifications | |||
| Fiber types | SM or MM | Connector types | FC/PC |
| Channel number | 1 | Estimated life cycle | ＞200millionrevolutions |
| Wavelength range | SM:1270-1650nm MM:650-1310nm | Vibration | MIL-STD-167-1A |
| Insertion loss | ＜3dB | Mechanical shock | MIL-STD-810G |
| Insertion loss ripple | ＜0.5dB | IP rating | IP68 |
| Return loss | ≥30dB | Max Optical power | 23dBm |
| Working temperature | -40～85℃ | Maximum speed | 2000rpm |
| Jacket types | / | Weight, approx | 20g |
| Storage temperature | -50~+85℃ | Package style | FC RECEPTACLE |
|
