DC5V Full Color Outdoor Waterproof Advertising LED Display P3 Trailer Screen Ip65

Categories Advertising LED Screens
Brand Name: SCXK
Model Number: SCXK-P3
Certification: CE,ISO,FCC,UL
Place of Origin: China(Mainland)
MOQ: 5 sqms
Price: negotiation
Payment Terms: T/T, Western Union, L/C, D/A, D/P, MoneyGram
Supply Ability: 3000 sqms/month
Delivery Time: 12-15 working days after receiving your down payment.
Packaging Details: Wooden and flight cases,it's up to you.
Color: Full Color
Control System: LSN
Module Size: 192*192mm
Cabinet Size: 576*576mm
Working Voltage: DC5V
Resolution: 64*64
Waterproof: IP65
Pixel Density: 111111dots/sqm
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

DC5V Full Color Outdoor Waterproof Advertising LED Display P3 Trailer Screen Ip65


2018 Hot Product Full Color Advertising LED Display P3 Trailer Screen Ip65


Features:

1. LED brightness is high and adjustable, which can meet the changing needs of customers in different environments. 2. Good flatness, good luminous uniformity, and mosaic-free display. 3. Wide viewing angle, the horizontal viewing angle can reach 120°, and the image display effect does not change much within this range. 4. Outdoor display screens can use virtual pixel display screens, and the resolution can be increased to 4 times that of real pixels, making the image softer and more realistic. 5. LED single lamp has low maintenance cost. 6. Unique exhaust fan design with good heat dissipation performance. 7. Environmental protection and energy saving.


Quick Detail:

1, High resolution at 15625pixels/square meter;
2, LED Chips: Epistar high brightness;
3, High brightness up to 7000cd/square meter;
4, Power Supply: Meanwell;
5, Control System: Linsn,Nova etc.


P3 Trailer Screen for outdoor
Resolution/mm3
Pixel configuration1R1G1B
Pixel density/pixels/m²111111/square meter
Module resolution64x64mm
Module size/mm192x192mm
View distance13-300m
Single point brightness adjustCan be added
Single point color adjustCan be added
White balance brightness>7500cd/square meter
Color temperature6500K-9500K
Horizontal view angle120(degrees)
Vertical view angle60(degrees)
Signal Process bit10 or 16bit
Grey process1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distancesInternet cable:100m, multimembrane:500m, monofilm:2km
Driving mode

alternating driving current

Scanning mode1/8 SCANNING
Frame rate60Hz
Refresh frequency>3000Hz
Control mode

Asynchronous,3G,4G,Wifi

Brightness adjusted rangeManual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point<1/10000
Working hours≥72hours
Mean Time Between Failure>5000hours
Life time100000hours
Life-all-white(brightness halving)50000hours
Environment temperature rangeOperating temperature range: -20-45℃
Self-check technologyLED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoringRemote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environmentWindowsNT,Windows1999,WindowsXP
Luminous point width between centresDeviation<3%
Brightness uniformity<10%
WaterproofIP65
Color uniformity(chromaticity coordinate)±0.003
Power supply requestAC85-264V(50Hz-60Hz)
Contrast(1000:1)
System protectionMoistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)working:10-95%
Humidity(storing)storing:10-95%

____________________________________FAQ____________________________________


Q1:How would I do when something was wrong with the screen?

A1:Professional engineers would offer onsite maintenance to your country.


Q2:How would I select LED screen that I need?

A2:The lower Pixel pitch,the more density,the more clear, the more expensive as well.


Q3:Where LED screen can be applied?

A3:It is seen everwhere in your life.Mall advertising;bank queue system,taxi top board ,stage backgrounddisplay and more.
