| Categories | CO2 laser marking machine |
|---|---|
| working accuracy: | 0.001mm |
| graphic format supported: | AI, PLT, jPg, DXF |
| laser type: | CO2 |
| condition: | New |
| Marking Depth: | 0.01-0.1mm |
| Marking Speed: | ≤7000 mm/s |
| cnc or not: | NO |
| Cooling System: | Air Cooling |
| Place of Origin: | Hubei, China |
| Brand Name: | hgnova |
| weight (kg): | 80 |
| key selling points: | High Productivity |
| warranty: | 1 Year |
| mode of operation: | Pulsed |
| configuration: | stand-alone |
| feature: | Air-cooled |
| Product name: | CO2 Flying Laser Marking Machine |
| Laser source: | Co2 Laser Metal Tube |
| Pulse Repetition Frequency: | 0~25kHz |
| Applicable Material: | Non-metal Materials |
| Laser wavelength: | 10.6um |
| Working area: | 70*70mm/110*110mm/140*140mm*175*175mm |
| File format: | PLT,DXF,AI,JPG,PNG |
| Certification: | ISO CE |
| Company Info. |
| Wuhan Hgguanghe Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Model | GH-30C-line |
Laser Type | CO2 |
Laser Power | 30W |
Laser Wavelength | 10.6um |
Pulse Repetition Frequency | 0~25kHz |
Marking Area | 70*70mm 110*110mm 140mm*140mm 175mm*175mm |
Marking Speed | F=160mm, ≤7000mm/s |
Minimum Line Width | 0.01mm |
Minimum Character | 0.1mm |
Repeated Precision | ±0.001mm |
Life-span of Fiber Laser Module | 100 000hours |
Control machine size | 210×400×450mm |
Marking control system | 10 inch touch screen, customized control card and marking software
by hglaser |
Elevating Axis | Up and down: 600-1000mm, front and back 0-150mm, 0-90 degree
rotation |
Cooling method | Air Cooling |
Power Supply | 1.2KW/AC220V/50Hz，5% |
Temperature of Operation Environment | 10~35°C |
Ambient humidity | 10%＜RH＜90%(if beyond the humidity range, the air conditioning will
be needed) |
Oil mist, condensation | It is not allowed. |
|
