Factory Price 55/110 Conical Twin Screw Extruder PVC Cable Trunking Extrusion Line with 1180mm Profile Size and 22KW Motor Power

Categories PVC Profile Extrusion Line
Brand Name: LB
Model Number: LB-1180
Certification: CE,ISO9001
Place of Origin: ZHANGJIAGANG
MOQ: 1 SET
Price: USD,EUR
Payment Terms: L/C,T/T
Supply Ability: 15 SETS PER MONTH
Delivery Time: 45 WORKING DAYS
Packaging Details: STANDARD PACKAGE
EXTRUDER TYPE: 55/110 CONICAL TWIN SCREW EXTRUDER
PROFILE'S SIZE: 1180MM
MOTOR POWER: 22KW
RAW MATERIAL: PVC POWDER & ADDITIVES
HAUL-OFFS: TWO INDEPENDENT TRACKS
CALIBRATION TABLE: EIGHT MTERS LONG
PACKING METHOD: WOODEN BOX AND FILM PACKAGE
PROFILE SIZE: ACCORDING TO CUSTOMERS' DRAWING
DELIVERY TIME: WITHIN 90 DAYS
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Factory Price 55/110 Conical Twin Screw Extruder PVC Cable Trunking Extrusion Line with 1180mm Profile Size and 22KW Motor Power

Factory Price PVC Plastic Electric Cable Trunking Extrusion Line PVC Cable Trunk Making Machine

This specialized PVC profile cable trunk production line is engineered for manufacturing various PVC profiles including window and door profiles, ceiling panels, and cable trunking systems. Custom solutions and molds are developed based on specific profile drawings.
Production Process
  • PVC powder + additives → mixing
  • Material feeding → twin screw extrusion
  • Molding and calibration → vacuum forming
  • Haul-off → cutting → discharge racking
Key Features
  • Conical twin screw extruder compatible with both PVC powder and granules
  • Integrated degassing system for superior material plasticization
  • High-speed mold technology for enhanced productivity
  • Comprehensive PLC control system for centralized operation
Technical Specifications
ModelLB180LB240LB300LB600
Max Product Width (mm)180240300600
Screw ModelSJ55/110SJ65/132SJ65/132SJ80/156
Motor Power22KW37KW37KW55KW
Cooling Water (m³/h)57710
Compressor (m³/h)0.20.30.30.4
Total Length (m)18222225
Conical Twin Screw Extruder
Engineered specifically for processing dry PVC powder blends, our conical twin screw extruder ensures homogeneous mixing, superior plastification, and optimal conveying efficiency. The permanent magnet synchronous motor delivers high energy efficiency, while the integrated PLC system enables centralized control of the entire production line.
Plate Mould System
Features double-strand mold technology for PVC trunking production, significantly increasing output capacity. Advanced channel design provides exceptional flow performance, and precision manufacturing guarantees high-accuracy profile production.
Calibration Table
Constructed with a robust steel frame and SUS 304 stainless steel body, the calibration table incorporates multi-dimensional position adjustment. Strategic placement of water pumps and vacuum calibrators ensures rapid shaping and cooling of PVC profiles, with sufficient length for complete profile formation.
Haul-off & Cutting System
Even force distribution across caterpillar tracks delivers consistent hauling power. High-quality rubber components ensure reliable performance, while pneumatic pressure systems facilitate easy adjustment and product protection. Customizable cutting options include swarf-free and saw cutting methods.
Production Line Components
Complete PVC cable trunk making machine production line overview
Complete Production Line
Close-up view of conical twin screw extruder mechanism
Twin Screw Extruder
Calibration table and vacuum forming system
Calibration System
Haul-off and cutting machine combination unit
Haul-off & Cutting Unit
