| Categories | Fiber Optic Cable And Accessories |
|---|---|
| Model Number: | PC-C6AU-LSB1-WH-10M |
| ANSI/TIA Class: | 6A |
| Cable type: | U/UTP (Unshielded) |
| Type of conductor: | Hard wire |
| Interface, connector A: | RJ45 Plug |
| Interface characteristics: | Standard |
| connector A interface: | RJ45 Plug |
| length: | 10M |
| Brand Name: | Commscope |
| MOQ: | 1Pcs |
| Price: | Negotiate |
| Packaging Details: | Box |
| Delivery Time: | Based on inventory |
| Payment Terms: | T/T |
| Supply Ability: | Supply by project/batch |
| Company Info. |
| Hong Kong Starsurge Group Co., Limited |
| Verified Supplier |
| View Contact Details |
| Product List |
Advanced High-Density Networking Solution for 10GbE Applications
28AWG slim design enables 30% higher port density compared to standard Cat6A cables, perfect for crowded network cabinets and patch panels.
LSZH jacket material reduces smoke and toxic emissions during fire incidents, meeting strict B1 flammability standards for public spaces.
This high-performance Category 6A patch cord represents the next generation in network connectivity solutions. Designed specifically for environments where space optimization and safety compliance are critical, this 28AWG networking cable delivers exceptional transmission characteristics while maintaining compact dimensions. The U/UTP construction ensures compatibility with existing infrastructure while providing superior alien crosstalk performance.
| Specification Category | Technical Details | Performance Metrics |
|---|---|---|
| Electrical Properties | Transmission Standard | ANSI/TIA-568.2-D Cat6A, ISO/IEC 11801 Class Ea |
| Physical Characteristics | Conductor Specification | 28AWG Stranded Copper Conductors |
| Overall Diameter | 5.2 mm Compact Design | |
| Connector System | Interface Standard | 8P8C RJ45 T568B Wiring |
| Mechanical Durability | 750 Minimum Insertion Cycles | |
| Environmental Compliance | Operating Conditions | -10°C to +60°C Temperature Range |
| Safety Certification | LSZH Jacket, GB/T 31247 B1 Rated |
Ideal for high-density server racks, top-of-rack switching, and storage area networks where space optimization is critical.
Perfect for corporate networks, telecommunications rooms, and workstation connectivity in office environments.
The 28AWG Cat6A network cable significantly reduces cable tray congestion and improves airflow in enclosed cabinets. This slim patch cord enables cleaner installations and easier troubleshooting in complex network environments.
Despite its reduced size, this Ethernet cable maintains full Cat6A performance specifications, supporting 10 Gigabit Ethernet speeds with excellent signal-to-noise ratio and minimal insertion loss.
With 750+ insertion cycle rating and robust connector design, this networking cord withstands frequent reconfigurations common in dynamic IT environments, reducing maintenance costs and downtime.
CommScope provides comprehensive technical assistance for this high-performance network patch cord, including installation guidance, performance validation services, and compatibility verification with existing infrastructure. Our global support network ensures professional assistance for deployment challenges.
The reduced 5.2mm diameter of this networking cable allows for significantly more connections in limited space while maintaining full Cat6A performance, making it ideal for crowded network cabinets and data centers.
The Low Smoke Zero Halogen jacket material minimizes toxic fume emission and reduces smoke density during fire incidents, providing crucial additional evacuation time and protecting sensitive electronic equipment.
Yes, this high-quality Cat6A network cable is engineered to support IEEE 802.3bt Type 4 PoE++ applications, delivering up to 90W of power while maintaining signal integrity for data transmission.
|
