W Pale Security Galvanized Steel Palisade Fence Wrought Iron 1.8m Garden

Categories Steel Palisade Fencing
Brand Name: YUANHAI
Model Number: YH-PF
Certification: ISO9001
Place of Origin: CHINA
MOQ: 10Sets
Price: $5.5-13.6/㎡
Payment Terms: T/T,L/C
Supply Ability: 5000Sets Per Month
Delivery Time: 5-8 work days
Packaging Details: Powder Coated Frame Finishing And Fencing Trellis & Gates Type Palisade Fence Water Proof Paper+Pallet.Custom Packaging Is Also Available According To Your Details
Product Name: Steel Palisade Fencing
Key Work: Spear Top Steel Fence Panel
Rail: 50x50mm
Suggested Pale Thickness: 2-6mm
Height Above Ground: 4.2m
Picket Top: Round
Head Stype: Notched
Hole Size: φ10mm hole on the pale
Application: Yard wall
Surface Treatment: PVC Coated
Pale: 3.0mm
Mesh Shape: Square
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

W Pale Security Galvanized Steel Palisade Fence Wrought Iron 1.8m Garden

W Pale Security Galvanized Steel Palisade Fence Wrought Iron 1.8m Garden



Steel Palisade Fence Description


Palisade Fencing is the perfect solution to your boundary security fencing. As Palisade Fencing is supplied piece small it is easily adapted to most site conditions.
Security Steel Palisade is supplied in kit form with the flexible design allowing the fence to be erected so that it follows the contours of the ground forming a formidable deterrent against crime and vandalism. The kit form allows for easy installation.
It also comes in several different grades of materials. The thickness of the steel Palisade can be adjusted depending on the height of the fence and the sensitivity of the area the fence is situated in.


Steel Palisade Fence Specifications


Fence panel height
1m-6m
Fence panel width
1m-3m
Pale height
0.5m-6m
Pale width
W pale 65-75mm d pale 65-70mm
Pale thickness
1.5-3.0mm
Angle rail
40mmx40mm 50mmx50mm 63mmx63mm
Angle rail thickness
3mm-6mm
RSJ post
100mmx55mm 100mmx68mm 150mmx75mm
Square post
50mmx50mm 60mmx60mm 75mmx75mm 80mmx80mm
Square post thickness
1.5mm-4.0mm
Straight fishplates or post clamps
30mmx150mmx7mm 40mmx180mmx7mm
Bolts and nuts
M8XNo.34 for pale fixing M12xNo.4 for rail fixing

Steel Palisade Fence Pales-"W" section



Most useful vertical type of pales for palisade fencing, which is always the customers' first choice for pales.



Width
Thickness
Surface Treatment
Head
Height
68mm-70mm
2.0mm
Galvanized and electrostatic polyester coated
or Hot dipped galvanized
Single point
Triple point
1200mm-3000mm
2.5mm
3.0mm



Steel Palisade Fence Pales-"D" section


Compared with "W" profile pales, "D" profile is more economical.


Width



Thickness



Surface Treatment



Head



Height



60mm



2.0mm



Galvanized and electrostatic polyester coated
or Hot dipped galvanized



Single point
Triple point



1200mm-3000mm



2.5mm



3.0mm



Steel Palisade Fence Pale-Angle iron


Its cost is similar with "D" profile, but its structure is simpler than "D" profile.


Width
Thickness
Surface Treatment
Head
Height
40*40
2.0mm
3.0mm
Galvanized and electrostatic polyester coated or Hot dipped galvanized
Single point
Triple point
1200mm-3000mm


Steel Palisade Fence Application


Steel fence: All of the fence panels, posts, mounting hardware and gates are dipped in electracoat rust inhibitor after final assembly to prevent corrosion and are then powder coated for a premium finished product. Standard fences are in stock and shipping is more affordable than you think! wrought iron fencing systems will not only beef up the security of your residential or commercial property but will improve the appearance as well.

Palisade fences are used in highways, railways, utilities, commercial and industrial sites, airports, docks, waste recycling centers, schools, sports fields and leisure facilities.


Steel Palisade Fence Packing
