PE & Ceramic-Coated Battery Separator with 3-layer (PP/PE/PP) or Single-layer (PP) Structure and 20~25 μm Thickness for Li-Ion, Li-Sulfur, Na-K Batteries

PE & Ceramic-Coated Battery Separators (2320/2325/2400/2500) – Single/Double-Side for Li-Ion, Li-Sulfur, Na-K Batteries

Product Overview

Crafted through dry and uniaxial stretching processes, this separator features oblong, interconnected micropores for good conductivity. No solvents are used in manufacturing, making it environmentally friendly. Additionally, it boasts superior longitudinal strength and minimal transverse thermal shrinkage.

Structural Composition
Product NameXWELL 2320XWELL 2325XWELL 2400XWELL 2500
Description3-layer (PP/PE/PP)3-layer (PP/PE/PP)Single-layer (PP)Single-layer (PP)
Width (mm)60/10060/10060/10060/100
Length (m)100100100100
Thickness (μm)20252525
Air Permeability (JIS) (Seconds)530645620200
Porosity (%)39394155
Heat Shrinkage TD 105℃/1h (%)0000
Heat Shrinkage MD 105℃/1h (%)1.5 / 53.0 / 5.02.3 / 5.01.1 / 5.0
Tensile Strength TD (Kg/cm²)156 / 115150 / 80140 / 70130 / 80
Tensile Strength MD (Kg/cm²)2040 / 15001900 / 10001420 / 7001170 / 770
Puncture Strength (gf)400 / 360450 / 380450 / 340325 / 200
Storage and Transportation
  1. Packaging Material: Plastic bag + carton packaging
  2. Storage Conditions: Sealed storage at room temperature
  3. Storage Period: 2 years from the production date
  4. Hazard Class: Class 4 (Hazardous Goods Classification and Operation Specifications)
  5. Packaging Class: Class Ⅲ (Packaging Class Ratings)
