| Categories | Power Converter System |
|---|---|
| Brand Name: | RUSEN |
| Model Number: | PCS-A50-MG |
| Certification: | IEC/EN 62109-1/-2, EN 62477-1, IEC/EN 61000-6-2/-6-4, EN 50549-1/-10, NRS 097-2-1:2017 ASGC, GB/T 34120, GB/T 34133, CGC-R46103:2018A, PTPIREE REV1.2: 2024 TYPE B |
| Place of Origin: | China |
| MOQ: | 1pcs |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 1000 |
| Delivery Time: | 3-30days |
| Model: | PCS-A50-MG |
| Power Rating: | 50KW |
| Max Efficiency: | 96.5% |
| Operating Temperature Range: | -30 ~ 55℃ |
| Battery Compatibility: | Li-ion / User-defined |
| Rated Battery Voltage: | 320-850V |
| Cooling Method: | Automatic |
| Input Voltage Range: | 50/60Hz |
| PV INPUT DC voltage, current: | 320~850 |
| Communication InterfaceInterface: | RS485/Wifi/GPRS/CAN/TCP/IP |
| Certifications: | IEC/EN 62109-1/-2, EN 62477-1, IEC/EN 61000-6-2/-6-4, EN 50549-1/-10, NRS 097-2-1:2017 ASGC, GB/T 34120, GB/T 34133, CGC-R46103:2018A, PTPIREE REV1.2: 2024 TYPE B |
| Warranty: | 5 years |
| Company Info. |
| RESUN ENERGY CO,.LTD |
| Verified Supplier |
| View Contact Details |
| Product List |
• Support fine adjustment of active/reactive power, dynamically
adjust output parameters according to load demand, and achieve
efficient utilization of power resources.
• Integrate multiple working modes, adapt to different scenarios
such as grid connected and off grid power supply, and meet the
operational requirements of energy storage systems.
• Accurately control power output, flexibly adapt to complex working
conditions, and provide stable solutions for new energy systems.
| Model | PCS-A50-MG |
| DC(battery) | |
| Voltage range (V) | 320~850 |
| Max. current (A) | 178 |
| AC(on-grid) | |
| Max. output power (kW) | 55 |
| Rated output power (kW) | 50 |
| Rated voltage (V) | 400 |
| Voltage range (V) | 320~460 |
| Rated current (A) | 72 |
| Max. output current (A) | 80 |
| Rated frequency (Hz) | 50/60 |
| Frequency range (Hz) | 45~55 / 55~65 |
| THDi | <3% |
| Power factor | 1leading~1lagging(settable) |
| Grid type | 3W+N+PE |
| AC(off-grid) | |
| Rated voltage (V) | 400 |
| THDu | <1% Linear ＜5% nonlinear |
| Rated frequency (Hz) | 50/60 |
| Overload capacity | 110% long-term |
| General data | |
| Max. efficiency | 96.5% |
| Ingress protection | IP21 |
| Noise emission (dB) | <70 |
| Operating temperature (℃) | -30 ～ +55 |
| Cooling | Forced air |
| Relative humidity | 0 ~95% non-condensing |
| Max. operating altitude (m) | 5,000(>3,000 derating) |
| Dimension W*D*H (mm) | 800*800*1,900 |
| Weight(kg) | 712 |
| Self-consumption | <0.5% |
| On/ off grid switching | Automatic |
| Display and communication | |
| Display | LCD touch-screen |
| BMS communication | RS485, CAN |
| EMS communication | RS485, TCP/IP |
| Certificates | IEC/EN 62109-1/-2, EN 62477-1, IEC/EN 61000-6-2/-6-4, EN
50549-1/-10, NRS 097-2-1:2017 ASGC, GB/T 34120, GB/T 34133, CGC-R46103:2018A, PTPIREE REV1.2: 2024 TYPE B |
|
