| Categories | Aluminum Led Street Light |
|---|---|
| Brand Name: | Die-casting Man |
| Model Number: | YASL-35-150 |
| Place of Origin: | Ningbo, China |
| Certification: | CE. EMC, LVD, ENEC, RoHs |
| MOQ: | 1PC |
| Price: | US$21.6 - US$44.6 |
| Packaging Details: | 1PC/CTN |
| Delivery Time: | 7-35DAYS |
| Payment Terms: | TT |
| Supply Ability: | 50000PCS/M |
| Warranty: | 3 Years |
| Voltage: | AC85-265V |
| Light Type: | Street Light |
| Beam Angle: | 120° |
| CRI: | >80 |
| Material: | Aluminum |
| IP Rating: | IP66 |
| Color: | Customized Ral. No. Such As Gray, Black, White |
| Company Info. |
| NingBo Die-Casting Man Technology Co.,ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Made of durable aluminum, this street light is designed to withstand harsh weather conditions and can operate within a wide working temperature range of -20℃ to 50℃. Its waterproof feature ensures that it can continue to function even during rainy seasons, making it a reliable option for outdoor lighting.
With a beam angle of 120°, this street light can cover a wide area and provide a bright and consistent light spread. Its 120W power rating allows it to emit strong illumination, making it an ideal choice for various applications such as illuminating streets, parking lots, and pathways.
The die-casting aluminum streetlamp housing of this light ensures that it is sturdy and can provide long-lasting service with minimal maintenance. It is available in different sizes ranging from 6m to 12m, making it suitable for various outdoor spaces.
In summary, the Aluminum Led Street Light is a waterproof 120W power high luminous lamp that offers reliable and consistent illumination. Its die-casting aluminum streetlamp housing and wide working temperature range make it an ideal solution for various outdoor lighting applications.
| Product Code | YASL-25-40(M) | YASL-25-60(M) | YASL-25-100(M) | YASL-25-150(M) | YASL-25-240(M) | |||
| Input Wattage(W) | 30-50 | 50-80 | 60-120 | 120-200 | 200-320 | |||
| Number of lenses(PCS) | 4 | 6 | 9 | 15 | 24 | |||
| Product Size(m m) | 563x215x110 | 613x240x110.2 | 654x256x114 | 780x287x114 | 834x341x114 | |||
| Packing Size(m m) | 610x250x260 | 660x280x260 | 710x300x260 | 810x330x260 | 860x380x260 | |||
| Net Weight (kgs) | 2.2 | 2.6 | 3.1 | 4 | 5.5 | |||
| Gross Weight (kgs) | 4.9 | 5.7 | 6.7 | 8.5 | 11.5 | |||
| Quantity of packing (pcs) | 2 | 2 | 2 | 2 | 2 | |||
| Installation Height (m) | 3～8 | 4～8 | 6～10 | 8～12 | 8～14 | |||
| Installation Pipe Diameter | 60 | 60 | 60 | 60 | 60/76 | |||
| adjustable angle | ±15°Adjustable | |||||||
| Materials | Housing:ADC12;Cover:Toughened Glass；Screws:304stainless screws | |||||||
| Spray colors | Double Grey； Sandy Black； Matt Silver | |||||||
| Led brand | LUMILEDS, OSRAM,CREE(Optional) | |||||||
| Led Specifications | 3030,5050(Optional) | |||||||
| Optical effect | 130～190 lm/w(Optional) | |||||||
| Color Temperature | 2700K,3000K,3500K,4000K,5000K,5700K,6500K(Optional)(Reference: Energy Star) | |||||||
| color rendering index | Ra≥70；Ra≥80；Ra≥90(Optional) | |||||||
| Optics | TYPEI,TYPEII,TYPEIII,TYPEV,TYPEIV(Optional) | |||||||
| Input Voltage | AC90～305V | |||||||
| Security level | ClassI/ClassII/Class1/Class2(Optional) | |||||||
| Frequency Range | 50/60Hz | |||||||
| Power Factor | PF≥0.95 | |||||||
| Protection | Overcurrent/Short circuit/Over temperature | |||||||
| Dimming mode | Time control/0-10V/ Optical control/Microwaves/DALI(Optional) | |||||||
| Lightning protection | 10KV/15KV/20KV(Optional) | |||||||
| Working conditions Range | -40 to 45℃,20% to 90%RH | |||||||
| Warranty | 5/8 year(Optional) | |||||||
| Protection level | IP66;GlassIK08/09/10(Optional),Lamp shell IK08. | |||||||
| Certifications | ENEC;CE;CB;IEC;RoHS;TUV;Lightning protection;LM-79;LM-80;IP66 | |||||||
The YASL-35 model offers a luminous flux of 4000LM and is available in power options of 30W, 150W, and 300W with a beam angle of 120° and CRI of >80. The working temperature ranges from -20℃ to 50℃.
In addition, Die-casting Man offers customization services for outdoor light post aluminium diecasting parts street light housing, adjustable arm mount, and dusk to dawn photocell. The product can also be equipped with a ZHAGA sensor for street lighting up to 100W.
Our Aluminum Led Street Light product comes with a comprehensive technical support and service package. Our team of experts is always available to assist with any questions or concerns you may have regarding the installation, operation, and maintenance of the product. Additionally, we offer regular maintenance services to ensure that your Aluminum Led Street Light is always functioning at optimal levels. Our technical support and services include: - Installation guidance - Troubleshooting assistance - Warranty support - Regular maintenance services - Spare parts and replacement services Please contact us for further information on our technical support and services offerings for the Aluminum Led Street Light product.
|
