Goodyear 1S3-013 Air Springs Mini Lobe Super Cushion Air Suspension Springs Sleeve Type

Categories Goodyear Air Spring
Brand Name: AIRSUSTECH
Model Number: G3013
Place of Origin: Guangzhou,China
Certification: ISO/TS16949:2009
MOQ: 5
Price: USD19.9/PC-USD49.9/PC
Packaging Details: Strong Carton Box or as Customers Requirement
Delivery Time: 5-8 Working Days
Payment Terms: T/T, Western Union, Paypal or Others
Supply Ability: 1000PCS/Week
Bolts: 5/16-18unc On One Plate
DIA. of Bottom Plate: 61.2 MM
Mode of operation: Single-acting
Application: Automatic Conveyor Belt Machine
Rubber Type: Natural Rubber And Cord
Material: Rubber Fabric Reinforced
Number of air bellows: One
Pressure Range: 0.2-0.8 M PA
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Goodyear 1S3-013 Air Springs Mini Lobe Super Cushion Air Suspension Springs Sleeve Type

Goodyear 1S3-013 Air Springs Mini Lobe Super-Cushion Air Suspension Springs Sleeve Type

Product Description:

The AIRSUSTECH Air Spring vibration that is typically experienced in industrial machinery can cause excessive wear and tear on equipment, which can lead to costly repairs and downtime. The Industrial Air Springs product effectively reduces this vibration with its Vibration Bellows technology. The bellows air bags work by absorbing the shock and vibration that is generated during equipment operation, resulting in smoother and more efficient performance. The 1S3-013 Air Springs product is a cost-effective solution for equipment owners who are looking to improve the performance and longevity of their machinery.


Technical Parameters: G3013

Actuator
Air Inlet1/8 in
Blind Tap for Mounting5/16-18 UNC x 0.44 Deep
Temperature Range [Min]-40 °F
Style No.YI-1S
Stroke Length [Max]2.1 in
Force @ Maximum Stroke (80 psi)120 lbf
Weight0.6 LB

Bellows Assembly
End ClosureStyle 2 End Retainer
Temperature Range [Max]150 °F
Upper End Plate Diameter2.4 in
Bellows TypeShaped Sleeve
Compressed Height1 1/2 in
Bumpersw/o Bumpers
Recommended Isolator Design Height [Min]2 in
Force @ Stroke (80 psi)580 lbf @ 1 in
Air Inlet TypeNPT
Force @ 1 in Stroke560 lbf
Lower End Plate Diameter3.4 in
Pressure [Max]100 psi
Recommended Isolator Design Height [Max]3 in

Cross References:


Goodyear1S3-013, 1S3 013, 1S3013
Firestone

W02-358-3000, W02 358 3000, W023583000

WO2-358-3000, WO2 358 3000, WO23583000

W02-358-3001, W023583001, W02 358 3001

WO2-358-3001, WO2 358 3001, WO23583001

Contitech

SK37-6P02, SK37 6P02, SK376P02

SK37-6PO2, SK37 6PO2, SK376P02

Prevost950208

Applications:


The AIRSUSTECH Air Springs for trucks, trailers buses, and cab & seat springs protect cargo, provide constant-level hauling, and deliver long, trouble-free service.The 1S3-013 air springs give your trucks, trailers and buses a new high in productivity and long life. They offer a quiet, cushioned ride. Truck, trailer and bus bodies last longer than with steel springs because there is less vibration. The driver rides in greater comfort, becomes less fatigued and stays more alert. Plus cargo has better protection from shock and vibration. Whenever you want to add an axle, AIRSUSTECH G3013 air springs fit right in. AIRSUSTECH air springs, when used with leveling valves, also maintain consistent trim regardless of the load. That means clearance heights remain constant,and that trailer floors are flush with loading dock floors for ease of loading and unloading. For driver comfort, load cushioning, and long life for your trucks, trailers, bus, and cab and seat springs specify AIRSUSTECH Air Springs.

Support and Services:


Our AIRSUSTECH Air Springs product comes with comprehensive technical support and services to ensure optimal performance and longevity of your equipment. Our experienced team of engineers and technicians are available to assist you with:


  • Product selection and sizing
  • Installation and maintenance
  • Troubleshooting and problem-solving
  • Custom design and development
  • Warranty and repair services

We are committed to providing top-notch customer service and support, and work closely with our clients to meet their specific needs. Contact us today to learn more about our technical support and services for our AIRSUSTECH Air Springs product.
