| Categories | Drone Accessories |
|---|---|
| Brand Name: | flysafe |
| Model Number: | N7 |
| Place of Origin: | Guangdong, China |
| MOQ: | 1 |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Delivery Time: | 5-8 work days |
| Main Processor: | STM32H743IIK6 (32 Bit Arm ® Cortex®-M7, 480MHz, 2MB memory, 1MB RAM) |
| Co-processor: | STM32F103 (32 Bit Arm® Cortex®-M3, 72MHz, 20KB SRAM) |
| Accelerometer / Gyro: | BMI088/ICM20689 |
| Electronic Compass: | IST8310 |
| Barometer: | MS5611 |
| Compatible Model: | PX4 / ArduPilot Firmware (Planes / 3-8 Axis Multirotors / Helicopters / VTOL / UGV / USV) |
| Dimensions: | 47 x 68 x 19 mm |
| Weight: | 57 g |
| Company Info. |
| Shenzhen Baohong intelligent manufacturing Co., LTD |
| Verified Supplier |
| View Contact Details |
| Product List |
The N7 flight controller is equipped with the H7 double-precision floating-point unit processor. lt adopts built-in dual lMU redundancy and internal shock absorption structure design, which endows the aircraft with high reliability. The N7 flight controller is compatible with both Ardupilot and PX4 open-source ecosystem to achieve adbundant application scenarios and provide stable and comprehensive systematic solutions for enthusiasts and industry application explorers of drones, unmanned vehicles and ships, smart robots.
| UART Serial Port | 4 |
| I2C | 3 |
| CAN | 1 |
| PWM Output | 8 x Standard PWM IO 5 x Programmable IO |
| RC Input (SBUS) | 1 |
| Power Module Input | 1 |
| GPS & Safety | 1 |
| USB (Type-C) | 1 |
| TF Card Slot | 1 |
| Compatible Model | PX4 / ArduPilot Firmware (Planes / Multirotors / Helicopters / VTOL / UGV / USV) |
| Power Module Voltage Input | 4.5 ~ 5.5 V |
| USB Voltage Input | 5 V (±0.25 V) |
| Servo Voltage Input | 0 ~ 10 V |
| Working Temperature | -20 ℃ ~ 65 ℃ |
| Dimensions | 47 x 68 x 19 mm |
| Weight | 57 g |
|
