| Categories | Electric Contact Pressure Gauge |
|---|---|
| Place of Origin: | Qingdao,China |
| Brand Name: | WYYW |
| Model Number: | YX-60C |
| Certification: | CE & ISO9001 |
| Packaging Details: | Inner plastic bag,export carton out side.Pallet optional. |
| Supply Ability: | 30-50k per month |
| MOQ: | 200PCS |
| Price: | Depends on total quantity |
| Warranty: | 1 year |
| Customized support: | OEM, ODM |
| Case size: | 60mm |
| pressure range: | 0-250MPa |
| Accuracy class: | 2.5% |
| connection size: | NPT, BSP(G,BF),BSPT(ZG,PT) 1/4" |
| Mounting: | bttom, back, panel |
| Port: | Qingdao |
| Delivery Time: | 5-30days |
| Payment Terms: | TT,LC.Alipay.Western Union |
| ADVANTAGES: | Moisture-proof,Wear resistant,Eco-friendly,High-durable |
| Company Info. |
| Qingdao Dazefengyang Meter& Welding Instruments Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
| Dials size | 2.5"(63mm),4"(100mm),6"(150mm) |
| Case | SS304, black steel |
| Pressure range | 0-100MPa, other scale unites bar, psi, kgf/cm2,ect. opitional |
| Movement | SS, brass |
| Socket | SS, brass |
| bourdon tube | phosphor bronze, SS |
| Dial plate and pointer | Aluminum |
| Window | Glass, safe glass |
| Connection size | 1/4" for 2", 2.5"case, 1/2" & 3/8" for 4" and 6" case |
| Connection thread | Metric thread, NPT, BSP(G,PF),BSPT(ZG,PT) |
| Liquid | Silicone, glycerine or dry |
| Mounting | Bottom, back and panel |
| Accuracy | 2.5"(63mm)-2.5%; 4"(100mm) and 6"(150mm)-1.6% |
| Control | Upper and lower limits contact control |
| Working voltage | AC220V, DC380V and DC24V opitional |
| Pressure limitation | Steady: 3/4x full scale value Fluctuation :2/3x full scale value Short time: full scale value |
1.Sample:samples are available,we have a good relationship with DHL,Fedex and other express company,we can decrease your cost for samples
2.Customise service:customise logo and OEM service is available for all clients
3.After service:if any questions about our products,we will not hesitate to solve it with our clients.Over more than 10 years exporting experience,we proved to be professional,reliable and competable.
If you are interested in our products, welcome to send inquiry !
|
