| PCB Type: | Flex Board |
| Layer: | 1 |
| Board thickness: | 0.10mm |
| Copper thickness: | N/A |
| Coverlay: | Black |
| Surface treatment: | Lead-free HASL |
| Silk screen: | White |
| Company Info. |
| Golden Triangle Group Ltd |
| View Contact Details |
| Product List |
| Description | Capability |
| Basic material | PI ( SF202) |
| TG value | 120 |
| Min line width | 0.28mm |
| Min line spacing | 0.22mm |
| Surface treatment | ENIG |
1. Do PCB panelizing as per 2x5
2. Add tooling hole and fiducial mark in breakways
3. Attach PI stiffener to the golden figure on the bottom layer, and the total thickness of stiffener is 0.33+/-0.05mm.
4. Attach 0.8mm FR4 stiffener to the pad on the bottom layer, and the total thickness of stiffener is 0.95+/-0.1mm.
5. Put in to production according to customer specified laminated stackup
Notes:
The following are some advantages of adding PI reinforcement in the
circuit board:
1. Enhance mechanical strength: Strengthen the anti-bending ability
of the gold fingers and other parts to make them more solid and
durable.
2. Reduce the risk of deformation: Reduce the chance of deformation
caused by external forces during insertion and removal or use.
3. Increase reliability: Improve the overall stability and
reliability of the circuit board.
|
