| Categories | Lifepo4 Battery Pack |
|---|---|
| Place of Origin: | Shenzhen, China |
| Brand Name: | Vodno |
| Battery connection: | 24S4P |
| Model: | VDO7226 |
| Nominal energy: | 1996.8Wh |
| Min. capacity@0.2C: | 25Ah |
| Nominal capacity@0.2C: | 26Ah |
| Nominal voltage: | 76.8V |
| MOQ: | Negotiation |
| Price: | Negotiation |
| Packaging Details: | Standard Packaging |
| Payment Terms: | L/C,T/T,etc. |
| Company Info. |
| Vodno Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
LIFEPO4 is the more efficient technology batteries , knocking out traditional lead acid batteries . VODNO provides a complete line of 12 ,24 and 48 volt batteries for use inRVS , Boats , Evs and off-grid applications and much more.
Overview
lithium batteries provide up to 10 times longer life than lead-acid batteries, and they still provide 80% of rated capacity after 2,000 cycles. Most lithium-ion batteries last five years or more. The average lead-acid battery lasts just two years. Lead-acid batteries also need to be maintained, requiring water replacement to avoid structural damage; if they aren’t maintained properly, their life span is shortened even further. Because lithium batteries require no active maintenance, a one-time purchase guarantees longevity.
How to make a decision for difference of battery materail

Specifications
| Model | VDO7226 | |||
| General Characteristics | ||||
| Nominal voltage | 76.8V | |||
| Nominal capacity@0.2C | 26Ah | |||
| Min. capacity@0.2C | 25Ah | |||
| Nominal energy | 1996.8Wh | |||
| Dimensions(W*D*H) | 270*230*170mm | |||
| Approx. weight(exclude cabinet) | 18Kg | |||
| Battery connection | 24S4P | |||
| Electrical Characteristics | ||||
| Operating voltage range | 60V~87.6V | |||
| Recommended charging voltage | 87.6V | |||
| Max. charging current | 20A | |||
| Max.continuous discharge current | 30A | |||
| Max.peak discharge current | 60A,<3S | |||
| Discharging cut-off voltage | 60v | |||
| Faraday charging efficiency | ≥98% | |||
| Energy charging efficiency | ≥92% | |||
| Operating conditions | ||||
| Operating temperature | Charge | 0℃~60℃ | ||
| Discharge | -20℃~60℃ | |||
| Storage temperature | -10℃~60℃ | |||
| Storage duration | 12Months @20℃~25℃ | |||
| Water dust resistance | IP30 | |||
| Lifecycle times | 2000 at 80% DOD | |||
Application
The energy storage battery is applicable for commercial or residential purposes.
1. Solar Energy Storage
2. Solar Street lighting
3. Light Electric Vehicle
4. E-bike/E-Rickshaw
5. Golf Cart
6. UPS




|
