| Categories | Pneumatic Solenoid Valves |
|---|---|
| Brand Name: | FESTO |
| Model Number: | CPE18-M1H-5J-1/4 |
| Place of Origin: | China |
| MOQ: | 1pc |
| Price: | EXW USD60-80 |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 300 pcs per month |
| Delivery Time: | 5-7 working days |
| Packaging Details: | Plastic bag, Carton |
| Model: | CPE18-M1H-5J-1/4 |
| Order no: | 163143 |
| Brand: | FESTO |
| pneumatic working port: | G1/4 |
| Construction width: | 18 mm |
| Product weight: | 270 g |
| Company Info. |
| Airwolf Automation |
| Verified Supplier |
| View Contact Details |
| Product List |
About product
1.Simple manifold design consisting of fixed-grid manifold blocks made from stable aluminium with 2 to 10 valve positions or modular manifold blocks made from durable polymer.
2.The connecting cables NEBV for sizes CPE10 and CPE14 have integrated current reduction.
3.All CPE valves therefore have a duty cycle of 100%.
Advantage
1.Convenient manual override.
2.Short switching times.
3.Shorter machine cycles .
4.Low power consumption.
5.Larger quantities .
6.Very short reaction times.
They can be mounted directly on site:
Flexible installation through individual mounting
On moving system components
On the cylinder
Technical Data
| Valve function | 5/2 double solenoid |
| Type of actuation | Electric |
| Construction width | 18 mm |
| Standard nominal flow rate | 1500 l/min |
| pneumatic working port | G1/4 |
| Operating voltage | 24V DC |
| Operating pressure | 0.2 MPa ... 1 MPa |
| Operating pressure | 2 bar ... 10 bar |
| Design | Piston gate valve |
| Approval | c UL us - Recognized (OL) |
| Maritime classification | See certificate |
| Degree of protection | IP65 With plug socket To IEC 60529 |
| Nominal size | 8 mm |
| Exhaust-air function | With flow control option |
| Sealing principle | Soft |
| Mounting position | optional |
| Manual override | Detenting via accessory Non-detenting |
| Type of piloting | Pilot actuated |
| Pilot air supply | Internal |
| Flow direction | Non-reversible |
| Symbol | 00991013 |
| Valve position code | Inscription label holder |
| lap | Positive overlap |
| Switching time reversal | 13 ms |
| Duty cycle | 100% |
| Characteristic coil data | 24 V DC: 1.5 W |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Product weight | 270 g |
| Electrical connection | Type C |
| Type of mounting | With through-hole |
| Pilot exhaust port 82 | M5 |
| Pilot exhaust port 84 | M5 |
| Pilot air port 12 | M5 |
| Pilot air port 14 | M5 |
| Pneumatic connection, port 1 | G1/4 |
| Pneumatic connection, port 2 | G1/4 |
| Pneumatic connection, port 3 | G1/4 |
| Pneumatic connection, port 4 | G1/4 |
| Pneumatic connection, port 5 | G1/4 |
| Note on materials | RoHS-compliant |
| Material seals | NBR |
| Material housing | Die-cast aluminium |
Product picture
