Fire Resistant Compressed Fibre Cement Board , External Cement Sheet Wall Panels

UV Coated Exterior Wall Decorative Reinforced Fireproof Fiber Cement Board 100% Free Asbestos

1. Galvanized Metal Frame

a.The top and bottom keels are fixed respectively top floor and on floor with expansion bolts.

b. The vertical keel should be aligned well according to the requirement (generally being 612 mm) with

laterally supporting keel installed.

2. Board Material Package Fixed

a. Cutting the board material to the dimensions needed (about 10mm lower than wall height)

b. Board material is fixed on keel in anchoring seam way with tapping screw: the interval of tapping screw is generally

about 200~250mm with screws sinking 0.5mm under the board face.

c. The expansion seam of about 4mm between boards should be kept.

d. The shrouding should be fixed from the middle to the four sides and cannot be operated at multipoint simultaneously

to avoid generating inner stress to make board material bucking.

e. Before board being packaged and fixed, depending the needs, glass cotton or rock cotton can be filled

Ningbo Fet Building Materials&Technology Co.,Ltd was founded in 2003 in Ningbo City,located in the south of Shanghai,50km from Ningbo port.

We are the biggest professional manufacture of fiber cement board,calcium silciate board in China by 4 automic production lines.Our factory covers an area of 600,000 square meters with the annual capacity of 20,000.000 square meters.

We have a high technological content and are recognized as the provincial scientific and technological novelty.The products are tested by Intertek,SGS,TUV,PSV,our enterprise was approved by ISO 9001:2008 and ISO14001:2001,is supplying the customers in USA,Middle East,Australia,Africa,Europe,South Asia and so on.

The quantity we export take 60% of the whole production.

Sincerely welcome more friends to cooperate with us!
