| Categories | Semi Trailer Trucks |
|---|---|
| Brand Name: | CIVL |
| Model Number: | CIVL |
| Certification: | ISO,CCC |
| Place of Origin: | China |
| MOQ: | 1 |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10000units/half year |
| Delivery Time: | Within 35 days |
| Packaging Details: | nude |
| Material: | q345 |
| color: | option |
| logo: | option |
| warranty: | yes |
| axle: | 3pcs |
| Product Name: | Dropside Semi Trailer Truck | Model: | 3 Axles 30-60Tons |
|---|---|---|---|
| Fifth Wheel: | #50, #90 | Loading Capacity: | 30-60tons |
| Dimension Of Flat: | 12600*3000mm | Axles: | 3X16 Tons |
| Material: | Carbon Steel Or Mn Steel | Landing Gear: | 28T JOST |
Description:
Dropside Cargo Semi Trailer Truck 3 Axles 30-60Tons 13-16m SINOTRUK INTERNATIONAL
You can choose 2 or 3 Axles, which can loading 20-70 Tons.
This kind of semi trailer special used in logistic industry, with high loading capacity,
light self-weight, it's a high cost effective products.
It's our competitive products, which exported to so many countries, especially Asia and Africa countries.
Such as Philippines, Vietnam, Congo, Ethiopia and so on.
Our company semi trailer truck series,is applied to the transportation of all kinds of
mechanical equipment, big size articles,road construction equipment ,big size tank body
power station equipment and all kinds of steels .widely using ,high efficiency .
Specification:
| Dropside Cargo Semi Trailer Truck 3 Axles 30-60Tons 13-16m SINOTRUK INTERNATIONAL | |
| Model | 3 Axles 60Tons |
| Axle | FUWA brand, 16ton, 3 Sets |
| Main beam | Beam height: 500mm Upper plate: 10mm Double Middle plate: 6 mm Down plate: 12mm |
| Dimension of cargo body | 13000*3000*600+1500mm |
| Material | Carbon steel or Mn steel |
| Gross vehicle weight | 70000kgs |
| King pin | #90 |
| Support leg | JOST Standard 28T |
| Suspension | Normal suspension |
| Thickness leaf spring | 10/10/10 |
| Tire/Rim | 1200R20, 13pcs, 8.5, 12 pcs |
| Brake Chamber | Standard 6 pcs |
| Spare wheel carrier | 2 pcs |
| Tool box | 1 pcs |
| Electrical System | Chinese standard 24C lighting system |
| Side Maker Lamp | LED lamp |
| Painting | Polyurethane Paint |
| Overall dimension | 16000×2500×3880(mm) |
| Color | White, red, green, golden and so on. |
Applications:
Dropside Cargo semi trailer for light or big size goods. suitable for long and short distance logistics.
Competitive Advantage:
1)competitive price, cost-effective
2)professional import and export dealing procedure, make customs clearance more high efficiency
3)based on strong technical support and top level technology make the trucks with high quality and more reliable
4)The main plane of the frame is low, which ensures the smooth transportation, and is suitable for carrying all kinds of engineering machinery, large equipment and steel.
5))Using three axis balance, double axis balance or rigid suspension, the mass balance block is arranged between the front and rear leaf springs.
6))the key parts adopt the world's top technology products
7)quick and efficient spare parts supply bring you more convenient
8)fast delivery time, we can arrange production according to your needs exactly and Quickly
FACTORY PTOS :
