| Brand Name: | ADI |
| Model Number: | AD5791BRUZ |
| Certification: | RoHS |
| Place of Origin: | Analog Devices Inc. |
| MOQ: | 75 PCS |
| Price: | Negotiable |
| Payment Terms: | L/C, D/A, D/P, T/T |
| Supply Ability: | 5K PCS |
| Delivery Time: | 2-3 DAYS |
| Packaging Details: | 75 PCS/Tube |
| Category: | Digital to Analog Converters (DAC) |
| Mfr: | Analog Devices Inc. |
| Package: | Tube |
| Number of Bits: | 20 |
| Number of D/A Converters: | 1 |
| Settling Time: | 1µs (Typ) |
| Output Type: | Voltage - Unbuffered |
| Data Interface: | SPI, DSP |
| Reference Type: | External |
| Voltage - Supply, Analog: | 7.5V ~ 16.5V, -2.5V ~ 16.5V |
| Voltage - Supply, Digital: | 2.7V ~ 5.5V |
| Operating Temperature: | -40°C ~ 125°C |
Quick Detail:
Manufacturer  | Analog Devices Inc.  |
Manufacturer Product Number  | AD5791BRUZ  |
Description  | IC DAC 20BIT V-OUT 20TSSOP  |
Detailed Description  | 20 Bit Digital to Analog Converter 1 20-TSSOP  |
Product Attributes:
TYPE  | DESCRIPTION  |
Category  | Digital to Analog Converters (DAC)  |
Mfr  | Analog Devices Inc.  |
Package  | Tube  |
Product Status  | Active  |
Number of Bits  | 20  |
Number of D/A Converters  | 1  |
Settling Time  | 1µs (Typ)  |
Output Type  | Voltage - Unbuffered  |
Differential Output  | No  |
Data Interface  | SPI, DSP  |
Reference Type  | External  |
Voltage - Supply, Analog  | 7.5V ~ 16.5V, -2.5V ~ 16.5V  |
Voltage - Supply, Digital  | 2.7V ~ 5.5V  |
INL/DNL (LSB)  | ±1, ±1  |
Architecture  | R-2R  |
Operating Temperature  | -40°C ~ 125°C  |
Package / Case  | 20-TSSOP (0.173", 4.40mm Width)  |
Supplier Device Package  | 20-TSSOP  |
Mounting Type  | Surface Mount  |
Base Product Number  | AD5791  |
Additional Resources:
| ATTRIBUTE | DESCRIPTION |
| Other Names | 505-AD5791BRUZ  |
-2735-AD5791BRUZ  | |
2156-AD5791BRUZ  | |
AD5791BRUZ-ND  | |
ANAANAAD5791BRUZ  | |
| Standard Package | 75 |
