| Categories | Interactive Flat Panel |
|---|---|
| Brand Name: | Astouch |
| Model Number: | A86-IWB07 |
| Certification: | SGS-CE, SGS-RoHS, FCC, ISO9001 |
| Place of Origin: | China |
| MOQ: | 1 piece |
| Payment Terms: | L/C, T/T, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 5000 pcs per Month |
| Delivery Time: | 5-10 working days |
| Packaging Details: | 1 piece into 1 master caron, for LCL shipment, will be packed with wooden frame; for full container load, pallet packaging |
| Active Area: | 1904.0(H) × 1096.0(V)mm |
| Max. Brightness: | 400cd/m² |
| Max. Resolution: | 3840*2160 |
| Panel Life: | 50000 hours |
| Viewing Angle: | H178/V178 |
| Touch Type: | IR touch with 40 points |
| Glass: | Anti Glare / Anti Reflective with MOHS-7 , Anti Blast Glass |
| RAM and ROM: | 4+32G, 8+128G optional |
| Feature: | Multifunctional |
| Camera: | 4K AI , Auto tracking |
| Microphone: | 8 Array- 12m pickup - Noise cancellation |
| Speakers: | 20Wx2 + 20Wx1 |
| Company Info. |
| Astouch Technology (Shenzhen) Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
| Specification | |||
| LCD Panel Parameter | Panel Size | 86inch (16:9) 4K Resolution | |
| Active Area | 1904.0(H) × 1096.0(V)mm | ||
| Model | A86-IWB07 | ||
| Max. Brightness | 400cd/m² | ||
| Max. Resolution | 3840*2160 | ||
| Contrast Ratio | 4000:1 | ||
| Panel Life | 50000 hours | ||
| Responsive Time | 8ms | ||
| Viewing Angle | H178/V178 | ||
| Touch Panel Parameter(optional) | Touch Max Resolution | 32767*32767 | |
| Touch Type | IR touch | ||
| Touch point | 20 touch points | ||
| Transparency | > 92%, Up to 100% | ||
| Scanning Speed | >50Scans/S | ||
| Response Speed | <6ms | ||
| Minimum identification diameter | 2mm | ||
| Touch accuracy | ±1mm | ||
| Communication | USB | ||
| Glass | MOHS 7 - Anti-glare | ||
| I/O | Front interfaces | USB 2.0*1 | |
| PC USB 3.0*1 | |||
| TOUCH USB*1 | |||
| HDMI IN*1 | |||
| POWER*1 | |||
| Speakers | Speakers 20W x 3 | ||
| Frame color | White | ||
| Glass Type | Anti Glare / Anti Reflective with MOHS-7 , Anti Blast Glass | ||
| Features | Support UHD video, pictures and music | ||
| Set up time on/off | |||
| Support Remote controller | |||
| Support Media Format | MPEG1/2/4, AVI, RM, WMV, DAT, JPEG, BMP, PPT, WORD, EXCEL, TXT, MP3, RMVB, SWF etc. | ||
| Temperature | Storage:-20 Celsius degree to 80 Celsius degree | ||
| Working: -10 Celsius degree to 65 Celsius degree | |||
| Fixing Method | Wall mounting (Default)/ Floor standing(Optional) | ||
| Other Features | Palm Rejection , Multi-touch gesture, AI Hand writing tracking ( Hand writing to digital form) White board save mode , | ||
| Dual system | Android system | CPU | Octa-Core A55*8 |
| GPU | Mali G52x4 | ||
| RAM | 4/8 GB DDR4 | ||
| Memory | 32/64/128 GB EMMC | ||
| Android system | Android 12.0 | ||
| Wireless | WIFI - 6 (2.4G+5G) wifi hotspot 2.4G+5G | ||
| Back Connections | TF Card*1 | ||
| USB 2.0*1 | |||
| USB 3.0* For integration of secondary camera | |||
| HDMI IN*2(HDMI 2.0) | |||
| Touch USB*1(USB2.0) | |||
| DP*1 | |||
| HDMI OUT*1 | |||
| LAN IN*1 | |||
| LAN OUT*1 | |||
| RS232*1 | |||
| Line OUT *1 | |||
| MIC IN*1 | |||
| VGA*1 | |||
| PC Audio IN*1 | |||
| COAX*1 | |||
| 2.1 Sound Trac *1 | |||
Front connections | USB 2.0*3 | ||
| USB 2.0*1 | |||
| Type-C 3.1 | |||
| HDMI IN*1 | |||
| OPS (OPTIONAL) | CPU | i3/I5/i7- all generations and configurations available | |
| software install | Google playstore, whiteboard, AIRGO cast wireless display, chrome, wps. VIP, | ||
| system language | Chinese (Traditional/Simplified), English, Russian, French, Spanish, Portuguese, Arabic, Italian, Japanese, Korean, Polish, Thai | ||
| Power Supply | AC 110V-240V, 50HZ/60HZ | ||
| Carton Dimension | 1888*260*1200mm | ||
| GW | 80kg | ||
| Product Weight | 90kg | ||
| Built-in Camera(optional) | 4K AI camera @ 30 fps; with Auto tracking | ||
| Built-in Microphone(optional) | 8 microphone array , pickup distance 12 m, echo cancellation, noise reduction, Voice tracking | ||
| whiteboard software | Free | ||
| Wireless display | AirGo Cast , Wired and wireless projection upto 4K , | ||
| Accessories | remote control*1, touch pen*2, wall mount bracket*1, etc. | ||
| Applications | Meeting, education,etc. | ||
| Certificate Approval | CE,RoHS,CCC,FCC,ISO9001 | ||
| Warranty | Three years | ||
|
