High Capacity 36kW 3000L/H Double-Stage Vacuum Transformer Oil Purifier

High Capacity 36kW 3000L/H Double-Stage Vacuum Transformer Oil Purifier

36kW 3000L/H Vacuum Transformer Oil Purifier Description:

1)Sino-NSH-VFD is a dehydration and degassing unit with thermal and double-stage vacuum processing.

2)Sino-NSH-VFD is mainly used to improve the properties of insulating oils in electric power transformers and other oil filled electrical equipment. It can remove dissolved and free water, dissolved gas and particulate impurities effectively so as to increase special indexes of insulation oil.

3)Sino-NSH-VFD combines vacuum flashing evaporation technology and delaminating gradual-close filter technology to reach best performance of oil purification. Meanwhile, by integrating efficient thermal and double-stage vacuum, the breakdown voltage is highly improved, which can be increased from 25kV to over 70kV.

4)ino-NSH-VFD maintains optimized structure and safe controls so as to meet comprehensive requirement of ansformer manufacturers and service companies. ino-NSH-VFD maintains optimized structure and safe controls so as to meet comprehensive requirement of ansformer manufacturers and service companies.

Corollary Equipment-VR Vacuum Pump Set

SINO-NSH-VR is units create vacuum in transformer and other equipment with double-stage vacuum system.

36kW 3000L/H Transformer Oil Purifier Function:

The function of vacuum oil filter is to eliminate the particles, water, gas and other pollutants in the oil, and reduce the acid value. Make the oil dielectric strength, water content, gas content, acid value, dielectric loss and other key indicators to meet the requirements of qualified specifications, as far as possible to ensure the safe operation of users' electrical equipment.

Double-Stage Vacuum Transformer Oil Purifier Technical Parameters:

Other Optional for Transformer Oil/Insulation Oil:

VF series-- Single-Stage Vacuum Transformer oil Filtration machine.
VFD-R series-- Double-Stage Vacuum Black Insulation Oil Regeneration Machine

Sino-NSH Oil Purifier Manufacture Co., Ltd. is a high-tech company which is engaged in researching, developing and manufacturing purification equipments. Its parent company, Sino-NSH High-Tech Company, was established in 1992.

NSH regards technical innovation and all-round service as its philosophy. Taking advantage of human resources capital and absorbing domestic and foreign advanced purification technology, NSH is committed in making purification equipments. NSH has been authorized the ISO9001 Quality Management System Certificate and European CE Certificate, now NSH becomes the main manufacture base of purification machines in China. 　

NSH oil purification equipment series are extensively used in the fields of electric power, petroleum, natural gas, mechanical manufacture, steel, metallurgy, railway and aviation, etc. The main products covering 100 kinds of products can meet different needs of customers. For special demands of customers, we offer particular solutions.

Nowadays, the company’s sales network covers all the provinces in China and exports to more than twenty countries around the world.

NSH products earn its fame on high quality, advanced technology and excellent service in both domestic and foreign markets.

NSH products are not only able to lower customers' cost and secure risk effectively, but also solve the problem of the waste-oil-contaminate environment.

Join hands with NSH, and get accomplishments for you and us.
