| Categories | Commercial EV Charger |
|---|---|
| Brand Name: | Xidao |
| Model Number: | XD-DC1000-60KW |
| Place of Origin: | sichuan |
| MOQ: | 1 |
| Price: | negotiate |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 5000 per month |
| Delivery Time: | 15-30 work days |
| Packaging Details: | Wooden case packaging |
| Product name: | 60KW Commercial EV DC Charger CCS1 |
| AC Input Voltage Range(V): | 380±15%,3 phases+N+PE |
| Output Voltage and Current: | 200-1000V; 0~200A(single gun) |
| Output Power: | Double gun 60KW, single gun 30KW |
| Communication Interface: | Ethernet/Wifi/4G |
| Efficiency: | ≥96%(full load) |
| Protection Grade/Shell Material: | IP54/ 1.5mm sheet metal shell |
CCS1 60KW Fast DC Commercial EV Charger Station Ethernet/Wifi/4G With Payments OCPP1.6
Product Features
a. 1.5mm sheet metal material outer case enables longer durability.
b. 200V-1000V ultra/wide range charging.
c. dynamically allocate charging power according to the charging requirements to avoid tripping
d. High-efficiency module with a high power factor and efficiency of more than 96%
Product Parameters
| Technical Parameters | |
| Product Type | Integrated DC Charger |
| Product Model | XD-DC1000-60KW |
| Display Mode | 7" Color Touch Screen |
| AC Input Voltage Range(V) | 380±15%,3 phases+N+PE |
| AC Input Frequency(Hz) | 45~66Hz |
| Power Factor | ≥0.99 |
| Current Harmonics(THDI) | ≤5% |
| Efficiency | ≥96%(full load) |
| DC Output Voltage Range(V) | 200-1000VDC |
Output Voltage Range under Constant Power(V) | 300-1000VDC |
| DC Output Current(A) | 0~200A(single gun) |
| Output Power(KW) | Double gun 60KW, single gun 30KW |
| Length of Charging Gun(m) | 5 |
| Noise(dB) | <65 |
| Charging Operation | Swiping card |
| Running Indication | Power supply,charging,fault |
| Heat Dissipation Control | Air Cooling Refrigeration |
| BMS Auxiliary Power Supply(V) | 12/24 |
| Power Distribution | Equipartition/Intelligent Distribution/Switching |
| Altitude(m) | ≤2000 |
| Working Temperature(C) | -20~50 |
| Storage Temperature(℃) | -40~70 |
| Average Relative Humidity | 5%~95% |
| Protective Function | Lightning protection, over-load,short-circuit over-temperature, electric leakage, emergency stop protection etc. |
| Charging Selection | Automatic, timing, quantitation, fixed fee, appointment etc. |
| Communication Interface | CAN with standard configuration, Ethernet, RS485, RS232,GPRS |
| Standard | American Standard,CCS1, OCPP1.6 |
| Protection Grade/Shell Material | Outdoor IP54/ sheet metal shell |
| Product Introduction | 1. Friendly visual interface with multiple information displays, prompt messages, IC card information, etc. 2. Electricity collection system and charge accounting system provide records of earning and consumption. 3. When the electric vehicle is charging, if the battery is full, the machine will stop automatically and remindthe user through the indicator light. 4. In case of over-voltage, under-voltage, short-circuit, leakage and connection failure, the machine will stopcharging and alarm by indicator light. 5. Industrial design, strong temperature adaptability, long service life and IP54 protection level. 6. The production mode of the whole industrial chain ofcharging pile ensures the reliability of the hardware. 7. Self-developed charging software can be usedthrough OCPP. |
| Dimension(H*W*D)(mm) | 1870*800*542 |
Company Profile
Besides providing our EV chargers to our customers, Xiangdao Technology also provides application development services, if you are interested in developing a unique charging app for your own charging pile, do not hesitate to send us a message to request detailed information and start turning your ideas into reality
Since 2004, our company has been dedicated to developing applications to provide the best service to various customers, our 20 years of experience in application development allows us to be one of the best and most experienced companies in China.
Our quality software product has been used by many clients in retail, distribution, and VIP account management.
Chengdu Xiangdao Technology Co., Ltd. is a company specializing in the overall solution of development, design sales, and operation of new energy, including EV charging piles, fast charging stations, solar photovoltaic power generation systems, solar application products, etc. We are committed to providing total solutions for the application of new energy technologies.
In the future, we will continue to focus on the application of new energy technology, operate with integrity and work hard to create a green world.
NOTE:
1- OEM supported.
2- Any requirement please contact us to talk about the details.
3- We will reply you for your inquiry in 24 hours.
4- If you have any questions about the charger, please contact us.
5- The above for reference only, final price decide by the charger KW, please contact us to get the correct quote.
|
