200hp Marine Diesel inboard Engine WD415 CE certificate engine

PrevNext

200hp Marine Diesel inboard Engine WD415 CE certificate engine

Item No.: WD415- 001
AddThis Sharing Buttons
Share to FacebookFacebookShare to TwitterTwitterShare to LinkedInLinkedInShare to PinterestPinterestShare to MoreAddThis
Condition: New
Engine: 4 Stroke
Fuel Type: Diesel
Cylinders: 6
Engine Position: Inboard
Dimensions (L x W x H) (mm): 1921*830*1791mm
marine products: marine motor
Order Number: WD41524C01
intake mode: turbocharged
Rated power: 202-240KW
INQUIRY
Description
Product Description
200hp Marine Diesel inboard Engine WD415 CE certificate engine
Sinotruk marine engine devided into for series, that is WD615, WD415, WD615.57, and D12 series for main power engines and auxiliaries. Main power engines are devided into two categories, basic use and fishing boat use with speed 1500r/min,1800r/min,2100r/min(or 2000r/min). The basic includes turbocharged intercooled engine model and turbocharged model, and the turbocharged intercooled models are the same as truck engines, but adding marine special spares, such as marine intercooler, sea-fresh water heat-exchanger, monitor, PS8500 fuel injection pump(with parking electromagnet),sea water pump, SAE1# flywheel case, 14'flywheel, and flywheel connecting flange, supporter, the installment size is 740*1089.2(and for WD415 series is 740*789.2), the distance from crankshaft center height is 135. The fishing boat used engines based on the basic used have been changed into 4 slots fishing pulley, connecting flange(M14*1.5), diesle filter installed in the air-intake pipe and also add diesle pre-filter installed in the air-intake pipe, the installing size is 694*1145.5*140cm( for WD415series is 694*805.5*140cm). Main power engines can choose 6135 flywheel case, when replace with SAE1 flywheel case, please change the flywheel case and connecting flange.

Specifications

Model41516C41524C
TypeVertical, in-line, water-cooled, four-stroke, direct injection
Air inletTurbochargedTurbocharged and intercooled
NO. of cylinder4
Bore×stroke(mm×mm)126×130
NO. of valve/ cylinder2,4
Crankshaft rotation direction(look from the free end)clockwise
Ignition sequence1-3-4-2
Displacement (L)6.484L
Rated fuel consumption rate (g/kW h)215205
Maximum combustion pressure (MPa)13.514.5
Compression ratio17 to 1
Oil fuel consumption ratio(%)0.4
Starting modeElectric starting
Charge ratio1.85
Idle speed(r/min)600±50
Crankshaft typeIntegral type
Net weight(kg)800
Dimensions L×W×H (mm)1260×830×11701610×830×1170

details introduction

Double walled strengthened wide block

In order to improve the engine reliablity, Sinotruk Steyr engine is the first one in China market adopted the EURO3 enhanced wide cylinder body designed by UK RICARDO company. The action solved the defect of stiffness and strength for original Steyr big power engine cylinder body.

There are 8 slots for pulley and connecting flange, can satisfy many kinds of customers requirements. Fishing boat pulley can be adjusted for special application.

Cooling system

The Centrifugal pump fixed in front cylinder block time gear room, water pump scrollhousing and outlet and time gear roomca
