| Categories | PCB Low Pass Filter |
|---|---|
| Brand Name: | VIIP |
| Model Number: | VIP9-2B-01 |
| Certification: | CE UL TUV ROHS REACH |
| Place of Origin: | China |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 2000 pcs within 10-15 days |
| Packaging Details: | 33*33*18 |
| Type: | PCB Socket filter |
| Rated current: | 1A |
| case: | metal |
| Operating frequency: | 50/60HZ |
| Temperature range: | 25 / 085 / 21 |
| Application: | Electronic Equipments |
| Company Info. |
| Shenzhen VIIP Electronics Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
| Item | PCB Socket Filter |
| Model | VIP9-2B-01 |
| Original of country | China |
| Package Type | Surface Mount |
| Nominal Center Frequency | 150K-30MHZ |
| Insertion Loss | 60~90dB |
| Input Impedance | 50Ω |
| Rated Voltage | 110V/250V |
| Rated Current5 | 1A |
| Environmental Temperature | 40°C |
| Temperature Range | -25℃~+85℃ |
| Operating Frequency | 50/60HZ |
| Line to Line | 1500VDC |
| Line to Ground | 1500VDC |
| Samples | available |
| MOQ | Negotiated |
| Price | Negotiated |
| Lead Time | 15~20 workdays |
Features:
-- Specially designed for easy and fast PCB hole through mounting,safe and effective
-- Various current
-- VIP9-2B are two stage common mode filters ,excellent common and differential mode interference suppression effect with very compact structure .
Applications:
1. Exchange board
2. Alarm
3. controller
4. LCD
5. Satellite TV Systems
6. electrical and electronic equipment
Specifications:


|
