| Categories | Solar Power Panels |
|---|---|
| Brand Name: | HUAN NENG |
| Model Number: | KN7000-J |
| Certification: | CE, ISO 14001, ISO 9001 |
| Place of Origin: | Chongqing, China |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Payment Terms: | T/T, L/C, Western Union, MoneyGram |
| Supply Ability: | 20000 sets per month |
| Delivery Time: | 7-15 work days |
| Packaging Details: | Carton box packing for each set |
| Product name: | AVR Voltage Automatic Adjustment Silent Diesel Generator |
| Feature: | AVR Voltage Automatic Adjustment |
| Starting system: | electric start |
| Phase: | three/single |
| Feature2: | No/Low noise |
| Feature3: | Low energy consumption |
AVR Voltage Automatic Adjustment Silent Diesel Generator
Application:
Diesel generator sets/low noise diesel generator sets conform to relevant national standards such as GB2820-90. Low noise diesel generator sets include low noise workstations, low noise automatic generator sets, low noise car power plants and low noise trailer power plants. Various design types. Low-noise diesel generator sets have the advantages of stable operation, reliable operation, low emissions and low fuel consumption.
Features:
1. Low running noise
A highly efficient combustion system ensures complete combustion, a large muffler reduces exhaust noise, and the engine's sound is dampened by a double-wall structure and liner absorber.
2. Low oil warning system
The generator will automatically stop before the oil level reaches dangerous levels. It can only be restarted after the proper oil level has been restored.
3. Strong power
All generators are powered by four-stroke diesel engines.
Technical parameters:
| Model No. | KN7000-J | KN8000-J | KN9000-J | KN10000-J | |
| Engine | Model | 186F | 188F | 192F | 198F |
| Type | Vertical single cylinder, 4-stroke, air-cooled, direct injection | ||||
| Bore x Stroke | 86x72mm | 88x75mm | 92x75mm | 98x84mm | |
| Displacement | 410cc | 456cc | 499cc | 633cc | |
| Ignition system | Compression ignition | ||||
| Starting system | Electric | ||||
| Fuel loss rate | ≤281g/kw.h | ≤295g/kw.h | ≤310g/kw.h | ≤310g/kw.h | |
| Fuel type | Diesel: 0(summer)-10(winter)-35(severe cold) | ||||
| Oil capacity | 1.3 liters | 1.5 liters | 1.5 liters | 1.65 liters | |
| Generator | Rated voltage | 230V/400V | |||
| Rated frequency | 50Hz | ||||
| Max current | 23.9A | 28.2A | 32.6A | 39.1A | |
| Rated output power | 5.0KW | 6.0KW | 7.0KW | 8.0KW | |
| Max.output power | 5.5KW | 6.5KW | 7.5KW | 9.0KW | |
| Phase | Single/Three | ||||
| Power factor | 1.0/0.8 cos | ||||
| Insulation class | F grade | ||||
| Excitation way | AVR voltage automatic adjustment | ||||
| Accessory configuration | Control panel | Digital display table | |||
| Fuel indicator | Yes | ||||
| Oil alarm | Yes | ||||
| Battery capacity | 12V-32AH Maintenance-free battery | 12V-36AH Maintenance-free battery | |||
| Castor accessory | Standard | ||||
| Fuel capacity | 20 liters | 20 liters | 20 liters | 20 liters | |
| Others | Weight | 158kg | 160kg | 165kg | 216kg |
| Continous working time | 8h | ||||
| Size (L*W*H) | 105*61*80 | 102*67*93 | |||
| Packing | Standard carton | ||||
| Noise | 75 dBA/7m | 65 dBA/7m | |||
| Model No. | KN13000-J | KN18000-J | KN20000-J | |
| Engine | Model | EV80/292 | 2V98 | 2V98 |
| Type | V-type twin/in-line twin cylinder, 4-stroke, air-cooled, direct injection | |||
| Bore x Stroke | 86x72mm/ 92x75mm | 98x88mm | 98x88mm | |
| Displacement | 840cc/997cc | 1326cc | 1326cc | |
| Ignition system | Compression ignition | |||
| Starting system | Electric | |||
| Fuel loss rate | ≤270g/kw.h | ≤250g/kw.h | ≤250g/kw.h | |
| Fuel type | Diesel: 0(summer)-10(winter)-35(severe cold) | |||
| Oil capacity | 1.7/2.6 liters | 3.2 liters | 3.2 liters | |
| Generator | Rated voltage | 230V/400V | ||
| Rated frequency | 50Hz | |||
| Rated output power | 10KW | 15KW | 16KW | |
| Max current | 47.8A | 65.2A | 69.5A | |
| Max.output power | 11KW | 16KW | 18KW | |
| Phase | Single/Three | |||
| Insulation class | F grade | |||
| Power factor | 1.0/0.8 cos | |||
| Excitation way | AVR voltage automatic adjustment | |||
| Accessory configuration | Control panel | Digital display table | ||
| Fuel indicator | Yes | |||
| Oil protector | Yes | |||
| Battery capacity | 12V-36AH Maintenance-free battery | 12V-45AH Maintenance-free battery | ||
| Castor accessory | Standard | |||
| Fuel capacity | 25 liters | 30 liters | ||
| Others | Weight | 240kg | 330kg | 340kg |
| Continous working time | 8h | |||
Generator size (L*W*H)(cm) | 116*66*90 | 130*80*103 | ||
| Packing | Standard carton | |||
| Noise | 70 dBA/7m | 78 dBA/7m | ||
