| Categories | Access Control Board |
|---|---|
| Brand Name: | zkteco |
| Model Number: | c5 |
| Certification: | ce |
| Place of Origin: | China |
| MOQ: | 1 |
| Price: | 1 |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 111 |
| Delivery Time: | 5 |
| Packaging Details: | carton |
| Company Info. |
| KO TECHNOLOGY CO.,LIMITED |
| View Contact Details |
| Product List |
| C5S110 | C5S120 | C5S140 | |
| Number of Doors Controlled | 1 | 2 | 4 |
| Number of Readers Supported | Wiegand reader: 2 RS485 reader: 2 | Wiegand reader: 4 RS485 reader: 4 | Wiegand reader: 4 RS485 reader: 8 |
| Types of Readers Supported | 26-bit Wiegand, others upon request | 26-bit Wiegand, others upon request | 26-bit Wiegand, others upon request |
| Number of Inputs | 3 Exit Button: 1 Aux IN: 1 Door Status: 1 | 5 Exit Button: 2 Aux IN: 1 Door Status: 2 | 9 Exit Button: 4 Aux IN: 1 Door Status: 4 |
| Number of Outputs | 2 Lock: 1 Aux Output: 1 | 3 Lock: 2 Aux Output: 1 | 5 Lock: 4 Aux Output: 1 |
| Hardware | CPU: 1.2GHz Flash: 256Mb RAM: 128Mb | CPU: 1.2GHz Flash: 256Mb RAM: 128Mb | CPU: 1.2GHz Flash: 256Mb RAM: 128Mb |
| Card Holders Capacity | 100,000 | 100,000 | 100,000 |
| Log Events Capacity | 200,000 | 200,000 | 200,000 |
| Communication | TCP/IP and RS-485, WI-FI | TCP/IP and RS-485, WI-FI | TCP/IP and RS-485, WI-FI |
| Mounting | Wall Mount | Wall Mount | Wall Mount |
| Recommended Power Supply | 12V DC, 1.5A | 12V DC, 1.5A | 12V DC, 1.5A |
| Dimensions (L*W*H) | 160 x 140 x 31.6mm | 197 x 171 x 31.6mm | 197 x 171 x 31.6mm |
| Operating Temp | -10 ~ 50°C | -10 ~ 50°C | -10 ~ 50°C |
| Operating Humidity | 20% ~ 80% | 20% ~ 80% | 20% ~ 80% |
|
