e Mill Finish Cold Rolled Aluminum For Curtain Wall Thickness 1.0-4.0mm

ALUMINIUM SHEETS FOR CURTAIN WALL

NOMINATION : THE ALUMNIUM SHEETS IS APPLIED FOR CURATIN WALL
APPLICATION: CURTAIN WALL
ALLOY AND SPECIFICATION( NORMAL)

ALLOY, TEMPER, SIZE(mm)

ALLOY

TEMPER

THICKNESS(mm)

Width(mm)

Length(mm)

1050, 1060. 1100,8A06,3003,

5005

H14

H24

1.5-4.0

914-2 200

1 000-6000

3003,3004,5005,5052

H14,24

1.5 -4.0

TOLERANCE(mm)

THICKNESS	THICKNESS TOLERANCE	WIDTH TOLERANCE	LENGTH TOLERANCE
1. 5 -1. 6	PLUS MINUE 0.10
1. 5-2.0	PLUS MINUS 0. 11
2. 0-2-5	PLUS MINUS 0. 12	PLUS 3 0	PLUS 6
2.5-3-2	PLUS MINUS0.14
3.2	PLUS MINUS0-18

FLATNESS(mm)

ALLOY	FLATNESS(,mtn)
	WIDTH(mm)
	Less than 1800	MORE THAN 1800
1050,1060,1IOG,8A06,3003,3004	M3	W5
5005.5052	Less than 5	W7

CHEMICAL COMPOSITION

ALLOY	TEMPER	THICKNESS(,mm)	U.T.S MPa MPa		EXTENSION (5mm)
ALLOY	TEMPER	THICKNESS(,mm)	NO LESS THAN
1060	H14 H24	1. 5 -2. 0	85	65	8
1060	H14 H24	2. 0-4. 0	85-120	65	10
1050	H14 H24	1. 5-2. 0	95	75	6
1050	H14 H24	2- 0-4.0	95 -125	75	8
1100	.H14 H24	1. 5-2.0	110	95	5
1100	.H14 H24	>2. 0-4.0	110-145	95	6
8AO6	H14 H24	1-5-2. 0	100	—	6
8AO6	H14 H24	2.0-4. 0	100-145	—	8
3003	0	1.5-4.0	95 -130	35	25
	H14 H24	1.5-2.0	140	115	5
	H14 H24	2-0-4.0	120-170	115	8
3004	0	1-5-4.0	350-200	60	18
5005	0	1.5-4.0	105-145	35	21
	H14 H24	1 5-2.0	140	115	5
	H14 H24	2. 0-4.0	120-180	115	6
5052	0	1.5-4. 0	170-215	65	19

SURFACE QUALITY

SHEET EDGE SHALL BE VERY FLAT,NO BURR, CRACK

NO ROLLING MARKS, BLACK OR WHITE LINE, SCRACH, CORROSION APPEAR ON SURFACE.

Product Tags:

aluminium foil stock

flat rolled aluminum

e Mill Finish Cold Rolled Aluminum For Curtain Wall Thickness 1.0-4.0mm

Send your message to this supplier


*From:	Your email address is incorrect!
*To:	Guang Xi Baisheng Light Metal Material Co.Ltd
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Categories	Cold Rolled Aluminum
Brand Name:	GBS
Model Number:	GBS-MQB
Certification:	ISO
Place of Origin:	CHINA
MOQ:	6mts
Payment Terms:	D/A, L/C, D/P, T/T,
Supply Ability:	2000 mts per month
Delivery Time:	4-5 weeks
Packaging Details:	wooden box
Alloy:	AA1100/3003/3005/3105/5052
packing:	standard export wooden pallets
finish:	mill finish
Thickness:	1.0-4.0mm
max.width:	2600mm
Application:	cuatain wall

e Mill Finish Cold Rolled Aluminum For Curtain Wall Thickness 1.0-4.0mm

e Mill Finish Cold Rolled Aluminum For Curtain Wall Thickness 1.0-4.0mm

e Mill Finish Cold Rolled Aluminum For Curtain Wall Thickness 1.0-4.0mm

aluminium foil stock

flat rolled aluminum

e Mill Finish Cold Rolled Aluminum For Curtain Wall Thickness 1.0-4.0mm

Our main production lines：

One 1+4 hot rolling mill with max. Width 2600mm

4 cold rolling mills

15 super casting lines

3 slitting lines

3 cut-to-length lines

2 tension levelling and cleaning lines

4 coated finstock lines

Main products:

1. aluminium coils/strip for precoating

2. Aluminium foilstock/finstock/cablewrap

3. Aluminium commercial sheets and coils

4. Aluminium plates applicable for shipping,construction,transportation,packaging etc.

Annual cabability: 120,000mts
