Welded 316L 1 inch square steel Instrument Tubing Tig Welding 1/2'' X 0.065''

Welded 316L 1 inch square steel Instrument Tubing Tig Welding 1/2'' X 0.065''

Spezilla offers a complete line of annealed, seamless and welded stainless steel instrumentation tubing designed to meet the performance requirements of oil & gas industry. We stock all ASTM A269 bright annealed seamless and welded stainless steel instrumentation tubing sizes from 1/4''(6.35mm) to 2''(50.8mm) OD in 20ft. standard lengths. Custom lengths and sizes are available upon request. Dual certified stainless steel tubing 304/304L and 316/316L are the workhorse grades for a variety of instrumentation and hydraulic applications. This material is stocked in 20 foot lengths in both welded and seamless production forms.

Features:

1. Dual Certified Austenitic 316/316L Stainless Steel

2. Annealed Instrumentation Grade Tubing

3. Complies to / Exceeds ASTM A269 Standard

4. Chemically Cleaned and Passivated

5. Available in sizes from 1/4” to 1-1/2” OD

6. Metric Sizes Available

7. Minimum 2.5% Molybdenum by Weight

8. Good resistance to attacks in acidic environments

9. Good resistance to pitting in neutral chloride-bearing solutions

10. Good resistance to Stress Corrosion Cracking

11. Good weldability

12. Surface - Polished to 320 grit

13. Hardness of not more than Rb 90

Instrumentation Tubing / Hydraulic Tubing Size Range:

Outside Diameter: 1/16” through 4.00”

Wall Thickness: .010” through .250”

Welded Stainless Steel Instrumentation Tubing:

Governing Production Specifications – ASTM A249 and ASTM A269

Seamless Stainless Steel instrumentation Tubing:

Governing Production Specifications – ASTM A213 (average wall) and ASTM A269

Specification:

Material Standards:

Recommended Maximum Working Pressure For Seamless 316 Tubing in PSI (bar):

Common Standards of Stainless Steel for Instrumentation , Heat Exchangers:

ASTM A 213 Seamless Austenitic Alloy Steel for Boiler, Superheater & Heat Exchanger Tubes Grades TP 304/304L , TP 316/316L, TP 321, TP 347,

ASTM 249 Welded Austenitic Steel Boiler Superheater and Heat Exchange Tubes U Bending available Grades TP 304/304L , TP 316/316L, TP 321, TP 347

ASTM 268 Seamless and Welded Ferritic and Martensitic Stainless Steel Tubing for General Service TP 430

ASTM 269 Seamless and Welded Austenitic Stainless Steel Instrumentation & General Service Grades TP 304/304L , TP 316/316L, TP 321, TP 347, 904 L

ASTM A632 - 04(2009) Standard Specification for Seamless and Welded Austenitic Stainless Steel Tubing (Small-Diameter) for General Service For low diameter as upto 1.27 to 12.7 mm OD. Similar too Din 17455

Corrosion service Duplex stainless Steels

ASTM A 789 Welded Ferritic / Austenitic Stainless Steel Tubing for General Service TP 2205 S31803, S32760, 2507

ASTM A688 / A688M - 10 Standard Specification for Welded Austenitic Stainless Steel Feedwater Heater Tubes

ASTM A803 / A803M - 10 Standard Specification for Welded Ferritic Stainless Steel Feedwater Heater Tubes

Spezilla specialise in manufacturing high quality precision stainless steel tube and other corrosion resistant alloy tubes that are designed to industry and customer specifications. Our products are manufactured to the highest quality standards and are very competitively priced. Our mission is to provide customized, flawless, reliable, and affordable corrosion resistant steel tubes to the world.

Tube Type:            Welded, Welded & Drawn. Straight Length or Coils.

Tube Materials:      Austenitic:    304, 304L, 316L, 321, 316Ti, 317L, 904L, 254 SMO;

                                                   1.4301, 1.4307, 1.4401, 1.4404, 1.4541, 1.4571, 1.4539, 1.4547;

                              Duplex:         2205, 2507;  1.4462, 1.4410;

                              Ferritic:         409, 439, 441, 444; 1.4512, 1.4510, 1.4509, 1.4521;

                              Nickel Alloy:  800, 800H, 800HT, 825, C276; 1.4876, 1.4958, 1.4959, 2.4858, 2.4819;

                              Titanium:       Gr.1, Gr.2;

Tube Size:              O.D. 4.00 - 38.10MM, W.T. 0.30 - 3.0MM.

Tube Finish:           As Welded, Bright Annealed, Annealed & Pickled, Polished, Custom Cutting.

Tube Standards:    ASTM A249, A268, A269, A270, A688, A789, B338;

                               EN 10217-7 TC1 & TC2, EN 10296-2, EN10357 etc.

Applications:          Heat Exchangers, Food & Beverage, Heating Elements, Automative, Tube Manipulation etc.

Spezilla appreciates the opportunity to help you with your questions about our operations, our products, our services or any other aspect of our business. We understand the demands of placing orders and the need for fast quotes, so we guarantee a response in 24 hours or less.
