| Categories | Aluminum Feed Beam Profiles |
|---|---|
| Brand Name: | HUANYU |
| Model Number: | HYAH6063T6 |
| Place of Origin: | CHINA |
| MOQ: | 50PIECES |
| Price: | NEGOTIABLE |
| Payment Terms: | T/T |
| Supply Ability: | 70 METRIC TONS PER MONTH |
| Delivery Time: | 7-10 days |
| Packaging Details: | PLYWOOD CASE |
| Length: | 405MM |
| Density: | 2.78 g/cc |
| Ultimate Tensile Strength: | 186 MPa |
| Yield Tensile Strength: | 145 MPa |
| Melting Point: | 616-654 Celsius Degree |
| Elongation at Break Percentage: | 13% |
| Application: | Mining Industry |
| Processing Method: | CNC Machining |
| Company Info. |
| Chongqing Huanyu Aluminum Material Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Durable Industrial Aluminum Extrusion Profiles As 405mm Long Finished Holder For Mining Machining
Holder Length: 405mm
Holder Surface Treatment: Sandblasted & Anodized
Leadtime: 7~10 Days
Availability: 1,700pieces
6063 is often called architectural aluminum for two reasons. First, it has a surface finish that is far smoother than the other commercially available alloys. Second, its strength is significantly less than most other aluminum alloys.
| Weight % | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Each | Total |
|---|---|---|---|---|---|---|---|---|---|---|
| Minimum | 0.20 | 0.45 | ||||||||
| Maximum | 0.60 | 0.35 | 0.10 | 0.10 | 0.90 | 0.10 | 0.10 | 0.10 | 0.05 | 0.15 |
Remainder Aluminum
| Temper | Tensile | Hardness | ||||
|---|---|---|---|---|---|---|
| Ultimate | Yield | Elongation | Brinell | |||
| KSI | MPA | KSI | MPA | % | ||
| T5, T52 | 27 | 186 | 21 | 145 | 12 | 60 |
| T6 | 35 | 241 | 31 | 214 | 12 | 73 |
|
