Rotary Permanent 100*175mm Grinding Magnetic Chuck

XH42 rotary permanent magnetic chuck

Attention:

1. The Electromagnetic chuck should be supplied with rated voltage of 110 volts DC power. The rectifier and control device is already equiped in the host electrical equipment if used on grinding machine. If use alone can select sets of rectifying device directly.

2. For the safe operation, before installing and using must be measure insulation resistance between coil and grounding wire,it should not less than 500 MΩ measured by 500V megger.

3. There must be a cooling liquid under the condition of grinding,to avoid the workpieces so overheated that influence the precision of the working surface,or lead to burn out the coil.

4. The contact surface between the workpiece and the panel should not less than one pole pitch, in order to make full use of the chuck’s magnetic force.

5. After the chuck fixed on the machine,should self grinding one time to ensure the accuracy. If the working surface change rough or magnetic force decreased, can self grinding the working surface to ensure that the magneitc force will not decline.

Specification sheet

As a professional designer and manufacturer of magnetic products over 10 years, JYC technology Co.,ltd is always providing customers appro-priate solutions to holding and lifting materialduring machining progressing.

The huge range of our magnetic products includeElectro magnetic chuck(EMC) series, Permanentmagnetic chuck(PMC) series, Electro permanentmagnetic chuck(EPMC) series, Electro magneticlifter (EML),.Permanent magnetic lifter(PM-L),Electro permanent magnetic lifter (EPML),Iron remover, Demagnetizer, etc.

Magnet is widely used in industries like metallurgy, machinery, shipbuilding, electric power, mine, automobile manufacturing, rail transportation and so on.

There is mainly 3 kinds of magnet, permanent magnet, electromagnet, permanent electromagnet. different magnet is suitable for different areas, and as a professional supplier of magnetic tools, JYC technology is is always providing customers appropriate solutions for our customers.
