| Categories | Flat Plate Solar Collector |
|---|---|
| Brand Name: | PASSION/OEM |
| Model Number: | 2 sqm |
| Certification: | CE |
| Place of Origin: | CHINA |
| MOQ: | 1 |
| Price: | Negotiable |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 5000units/month |
| Delivery Time: | 10 working days |
| Packaging Details: | CARTONS/PLYWOOD CASE/PALLET |
| Header Material: | Copper TP2 |
| Header pipe: | Red Copper |
| Absorber Material: | Aluminum Full Plate |
| Cover Material: | Wove Toughened Glass |
| Frame: | Anodised Aluminium Alloy |
| Dimension LxWxH (mm): | 2000*1000*80 |
| Collector: | Flat Plate |
| Insulation Material: | Fiberglass |
| Company Info. |
| JIAXING PASSION NEW ENERGY TECHNOLOGY CO., LTD. |
| Verified Supplier |
| View Contact Details |
| Product List |
High Absorption Blue Titanium Flat Plate Solar Collector Anodised Aluminium Alloy Wove Toughened Glass
Feature
1. high efficiency &attractive appearance.
2. customized service.
3. easy installation and flow maintenance.
4. low cost & high socio-economic benefits.
5. 15 years' life span with 5 years warranty.
6. well wind , snow and hailstone resistance.
Working Principle
Solar radiation passes through transparent cover plate and reaches heat absorbed layer of plate . The water inside the copper pipe becomes hot and rise in the top of the water tank .
So the hole system is always circulating continuously heating .
Detail Specification flat plate collector
dimension: 2000*1000*80mm
the work temperature:- 35C-200C
the work pressure: 0.8Mpa
it can generate 100L hot water (50Celsius) per day
the aluminum shell
the boronsillicon glass cover
all copper material conduct medium in the collector
We can provide the clients the whole set include water tank solar collector and work station,the clients also can purchase the collector only,them can be optional
| Comply with | SOLAR KEYMARK/CE |
| EN12975 | |
| Fins | Aluminum absorber type |
| Tube for pump circulation | 8 * δ0.5 *1886, 8pcs copper |
| Manifold tube for grids | 22 * δ0.8*1060 ,2pcs copper |
| Minimum efficiency | 80%-90% |
| Absorption factor | absorption~95% |
| Emission factor | emission ~18% |
| Insulation | Back: 30 mm fiber glass cotton ,30kg/sq.m |
| Side: 15mm fiber glass cotton, 60kg/sq.m | |
| Glazing | 4mm tempered glass Fixed on casing by silicon or EPDM |
| Area available | 5m2(2*2.5m)--roof mounted. |
| Backing Sheet | 0.3mm galvanized plate |
| Net Weight(kg) | 32.5 |
| Gross Weight(kg) | 37 |
| Working Pressure | 0.6Mpa |
| Testing Pressure | 1.2Mpa for 5 minutes |
| Net dimension L*W*T(mm) | 2000*1000*80 |
| Package Dimension(mm) | 2010*1010*95 |
| Package | Cartoon |
| Cartoon size | 0.2CBM |
Packaging & Delivery
Packaging Details: STANDARD EXPORT CARTONS,WOODEN BOX FOR SAMPLES.
Delivery Detail: 15DAYS FOR FULL CONTAINERS,10 DAYS FOR SAMPLES.
Terms:
1. OEM or Customized design available.
2. Payment terms: 30% in advance and 70% against copy of B/L or
L/C, For sample T/T 100% in advance.
3. Delivery terms: 15 working days after receiving deposit or
original L/C.
4. Warranty: 5 years.
5. Minimum quantity: 3
6. Package:
Standard export package with Logo or the package you want on the basis of OEM.
For LCL, extra wooden boxes will be added.
Warranty:
10 years international responsibility for Flat Plate Panel Solar Collector due to original quality problems.
FAQ
Payment terms: T/T, L/C, Paypal, Western union all support
Delivery time: Sample order 3 working days, Container order 10 working days.
Minimum order quantity: 1 PC
Guarantee period:5 years
OEM service: Support (Print logo on carton for free)
|
