Name: Customized software remote control tablet with Android system for home automation
Brand: SIBO
Price: 1 USD

Home > Remote Control >

Customized software, remote control tablet with Android system for home automation

Categories	7" tablet pc for home automation
Brand Name:	SIBO
Model Number:	Q896S
Certification:	CE, FCC
Place of Origin:	Shenzhen
MOQ:	2 units
Payment Terms:	T/T
Delivery Time:	5-25 working days
Packaging Details:	10 pcs in one carton
OS:	Android 6.0
CPU:	Allwinner A83T 8-core
screen:	multiple capacitive touch screen
RAM:	2GB
ROM:	8GB
network:	wifi, 3G, Ethernet,blurtooth
power supply:	DC IN or POE
interface:	camera, USB, HDMI output, RJ45,DC IN
serial ports:	RS232, RS485, GPIO
Optional accessories:	NFC, three-colors LED, temperature sensor, light sensor
Bracket:	Onwall, inwall, glass wall, table
Supply Ability:	2000pcs/month

Contact Now

Add to Cart

Company Info.

Shenzhen Sibo Industrial & Development Co., Ltd.

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

Customized software, remote control tablet with Android system for home automation

Customized software, remote control tablet with Android system for home automation

Detailed Product Description

Features:

IPS Screen (G+G glass)
Three color led light on the top to show room status (blue, red, green)
Android OS
In wall / On wall version / Glass wall mount
HDMI, Serial port , GPIO , Uart interface
No buttons design
Slim Body with 3 Brackets for wall mounting
Camera & Mic
Support ROOT permissions for private application
No battery design
Auto power on
12V DC / 24V DC available for power
Auto web application (one web page can be showed only on the screen)
POE feature (IEEE 802.3 af)

Application :

Meeting romm Schedule,
Office control region,
Home Automation,
Industrial control

Customized Service:

Customized animation firmware with your logo (available in bulk order)
Temperature/Humidity Sensor
Customized USB jumper for app debugging

Standard accessories;

WIFI
Bluetooth
Camera
Power adapter

Optional accessories:

PoE
NFC RFID Reading module
LED indicating bar
Arduino Nano
RS232
RS485
GPIO

With multi color controllable Indicator on the top (red / green / blue), suitable for meeting room applications, home automation and control

Demo application software and source code will be provided for you to integrate LED control feature into your own software.

Specification:

Model Number		Q896S
Hardware Specs	Solution	Allwinner’s A83T processor
	CPU	Octa-core Cortex tm-7a CPU A83T 1.2Ghz
	Display	7 Inch IPS Display, Resolution:1024 x 600, Brightness: 350 cd/m2
	RAM	2GB
	Nand Flash	8GB

Software Feature	System	Google Android 6.0
	Audio	One Speaker 1 X 1 Watt (Integrated 3W Amplifier)
	Language	Support multi-languages

Interfaces	Back	Ethernet Interface(RJ45)
		HDMI Out
		USB 2.0 port USD HOST Mode Default, Optional: Jumper Cap for Device Mode
		DC IN Power Terminal (9V-36V)
		Optional:RS232,RS485,1xGPIO IN, 1xGPIO OUT

Network	WIFI+BLUETOOTH	WIFI (802.11b/g/n), Bluetooth 4.0 support BLE
	LAN Port	Ethernet RJ45

Power Supply	DC IN or PoE	DC 9V - 36V or PoE

Boot Up	Auto Boot	Auto Boot Up When Power Supplies

It is Wall Tablet / Desk Tablet, no battery , no buttons (with auto power on feature), it is a serial port Tablet , It is a GPIO tablet, all good features for home automation and so on...

A real POE tablet PC can works with POE standard of IEEE 8023.AF, compatible with 12V DC.

DC+ POE for power supply

Q896S INTERFACE:

1.HDMI OUT

2.CVBS IN(Removed)

3.DC IN (9-24V)

4.RJ45

5.USB

6.UART, IO , 3W AMP OUT

7.SLOTS FOR MOUNTING

8.SCREWS FOR MOUNTING

In wall installation :

Application:

Welcome OEM orders !
