| Categories | Lowboy Semi Trailer |
|---|---|
| Brand Name: | Starrailer |
| Model Number: | LB2-013 |
| Certification: | CCC |
| Place of Origin: | Shandong Province, China |
| MOQ: | 2 units |
| Price: | USD19,000~USD39,000 |
| Payment Terms: | T/T |
| Supply Ability: | 30 sets per month |
| Delivery Time: | 40 days after down payment received |
| Packaging Details: | 2 units/package transported by break-bulk-vessel or roll-on-roll-off-vessel |
| Type: | Terminal Trailer |
| Axle brand: | FUWA |
| Material: | Q345B |
| Size: | Buy's request |
| Use: | Transport containercontainers within container terminal. |
| Company Info. |
| Star Trailer Co.,Ltd |
| View Contact Details |
| Product List |
Click this link to talk to us:
Whatsapp: https://api.whatsapp.com/send?phone=8613864856071
YOUTUBE: https://www.youtube.com/user/BenjaminDuBin
Product Description
Material:
High tensile low alloy steel with 550 MPa yield strength is used
for fabricating H-beam and 350 MPa steel material for other
fabricated parts.
CIS: CHINA Industrial Standard
Frame:
Main Beams: 590 mm x 150 mm. Fabricated H-beam with 16mm x 150 mm.
Top and bottom flanges, 8mm web.
Cross Members: 8mm thick x 751mn wide x 400mm height fonned channel.
Side guide:
Four side guide block of 900 mm. (L) X 270 mm. (H) Of box structure
slope inside surface guiding container when loading. There are 50
mm. X 6 mm. Rubbing plate on the side guides. Each pair of side
guide are supported by bolster of a 200mm. X 200 mm. X 10mm. Square
tube and a 200 mm. X 73mm. Channel.
Rear guide:
On the rear bolster, there are two I40mm.(W) x 110 mm. (H) Box type
container guide/stopper on top of the
rear bolster. This guide/stopper will not affect the opening of the
container door on the trailer.
Stopper:6 gravity stoppers of 100 mm above the top surface of the
main beam
Rear bumper: 100mm x 100mm square tube bumper with Heavy-duty
vertical steel channel supports.
Ladder: One ladder at each side at the centre of the trailer
position between two 20’containers.
Safety side guard rail: 100mm x 50mm rectangular tube, fixed type.
Landing leg:
Fixed landing leg with the sandshoe.
Landing leg size: :200x200x10 square tube.
Kingpin & Plate:
10mm thick plate with 8mm thick fabricated“C” channel type king pin
support, 2”(50.8mm)diameter bolt on the kingpin.
Type: KZ1010 (JOST, CHINA)
Suspension:
Heavy duty tandem suspension with 12 leaf spring. (100 widths by
13mm thickness/leaf). Rated capacity is 2 x 16Tons.
Maker: MAG MC4/S 150-12
Axles:
l50x150 square axle. Ten stud ISO (M22xl.5) Manual slack adjuster.
Type:FUWA, MAX CAP:16000KG/axle@105km/h
Wheels:
8.0x 20 Steel disc wheels, ISO 10 holes, PCD 335nun , 280mm center
hole.
Type: sunrise CHINA
Tires:
11.00 - 20 Solid rubber tires
Type: Chaoyang/Double coin/ Triangle tire...
Brake system:
Dual line pneumatic service brake system.
Valve: WABCO RE6 · without ABS
Brake chamber: T30 service brake chamber on both axle Air coupling:
quick coupling type.
Electrical System:
12-volt lighting system with the seven-way receptacle.
Brake/tail lamp & turn signal lamp & reverse lamp.



Product Details:
Our customers
FAQ:
1. Can I have a sample of this type of trailer to test the quality?
Of course yes, my friend and our MOQ is 1 unit.
2. What's the delivery time and can you lower the price?
It depends on the quantity. Usually, it is within 40 days after the
receipt of deposit. And my friend, the more units, the lower
price...
3. Can I customise the trailer?
Yes, the design will be made according to your suggestion.
4. What's the payment terms?
30% by T/T as deposit and balance by T/T before delivery., or by
L/C at sight.
5. How do you ensure its quality?
There will be a warranty given to you to provide you with good
after-sade-support.
|   |
