| Categories | TFT LCD Module |
|---|---|
| Brand Name: | PVI |
| Model Number: | PW035XU1 |
| Certification: | ISO9001 |
| Place of Origin: | China |
| MOQ: | 1 |
| Payment Terms: | T/T, Paypal, Western Union, MoneyGram |
| Supply Ability: | 500PCS/DAY |
| Delivery Time: | 2-3 working days after payment confirmation |
| Packaging Details: | Antistatic bag, Bubble Bag, Foam Box and Carton Box. |
| Panel Size: | 10.4 inch |
| Aspect Ratio: | 4:3 (H:V) |
| Dot Pitch: | 0.088×0.264 mm (H×V) |
| Pixel Pitch: | 0.264×0.264 mm (H×V) |
| Outline Depth: | 6.0 (Typ.) mm |
| Holes & Brackets: | Face mounting holes |
| Company Info. |
| N&S ELECTRONIC CO., LIMITED |
| View Contact Details |
| Product List |
Full Color 3.5 Inch TFT LCD Module PW035XU1 Dot Matrix Anti - Glare Surface
<
| Panel Brand : | PVI |
| Panel Model : | PW035XU1 |
| Panel Type : | a-Si TFT-LCD , Panel |
| Panel Size : | 3.5 inch |
| Resolution : | 320(RGB)×234 |
| Display Mode : | TN, Normally White, Transmissive |
| Active Area : | 76.32×42.82 mm |
| Outline : | 88×53.5 mm |
| Surface : | Antiglare |
| Brightness : | 350 cd/m² (Typ.) |
| Contrast Ratio : | 400:1 (Typ.) |
| Display Colors : | Full color |
| Response Time : | 15/25 (Typ.)(Tr/Td) |
| Viewing Angle : | 60/60/40/50 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency : | 60Hz |
| Lamp Type : | 3S2P WLED Without Driver |
| Signal Interface : | TFT Specific Analog RGB , 30 pins |
| Input Voltage : | 3.3/5.0/17.0/-12.0V (Typ.)(VDD1/VDD2/VGH/VGL) |
<
| Vertical Frequency : | 60Hz |
| Reverse Scan : | Yes (U/D, L/R) |
| Total Power Consumption : | 482mW (Max.) |
| Time Controller (T-CON) : | Need external T-CON |
| Lamp Position : | Edge light type |
| Lamp Type : | WLED |
| Lamp Amount : | 3S2P |
| Lamp Shape : | 2 strings |
| Lamp Life Time : | 30K(Typ.) (Hours) |
| Lamp Voltage : | 10.8V (Typ.) |
| Lamp Current : | 20mA (Typ.) |
| Lamps Power Consumption : | 432W (Max.) |
| Interface Type : | Included in panel signal interface |
| Lamp Driver Board : | No |
Excellent service:
We mainly sell Industrial LCD panels and touch screens , providing information and technical consultation for all kinds of LCD screens and touch screens, Wehave many parts in stock ,such as the brand for GT/GUNZE,FUJITSU,HITECH,SIEMENS,HAKKO,WEINVIW,ELO parts. And 4.7-15 inches is between the various size of industrial screen, They are applicable to vehicles, medical equipments, injection molding machines ,industrial equipments etc.
new and original; we offer high quality, fast delivery, competitive price for our customers;
> Please send your RFQ(request for quoting) to get latest price;
> We will ship the items within 2 working days after receive the
payment;
> We can ship to you by UPS/DHL//EMS/Fedex. Please contact us
and we will use your preferred ways;
> We have a large stock and the prices are variable, so
sometimes the prices we post are not accurate. If needed, please
contact us for specific prices .
PVI PW035XU1 Packing Form :
Amount per Box : 132 pcs
Box Size : 455×375×190 mm (L×W×H)
Box Gross Weight : 8.0 Kgs
Pictures of PVI PW035XU1 :


packing.
|   |
