| Categories | Workshop Steel Structure |
|---|---|
| Brand Name: | SPDAR , Hongfa |
| Certification: | ISO9001:2008, AWS and BS EN ISO welding certificate by Singapore Setsco |
| Place of Origin: | Guangdong of China |
| MOQ: | 20 Ton or 1000 Square meter |
| Price: | Negotiable |
| Supply Ability: | 10000 metric ton/month |
| Delivery Time: | 15~45days |
| Packaging Details: | All steel members are put into one steel holder |
| Model Number: | 1500SQM |
| Size: | Customized |
| Drawing design: | Tekla, PKPM,Auto-CAD |
| Main-Steel Structure type: | H / I Section |
| Bracing Parts: | Angles/ Steel Bar/Hollow Pipe/ U Channels/Hollow Section |
| Purline: | C & Z section |
| Cladding System(wall & roof): | Single panel or Sandwich panel |
| Processing method: | Steel plate cutting & welding or Hot-rolled steel profiles |
| Derusting: | Ball blast |
| Surface treatment: | Painting or Hot-dip galvanized |
| Connection: | Bolts |
I Section Customized Workshop Steel Structure Galvanized Q345B & Q235B
Quick to fabricate
Easy to assemble
Long using time over 50 years
Low cost and maintenance
Environment friendly
Recyclable
Lighter weight
Excellent anti-shock and anti-impact ability
Application:
steel structure warehouse, workshop, hangar, garage, poultry house, container house, prefabricated home, high-rise building for office, shopping mall, hospital, dormitory, school, bus station, railway station, bridge, etc.
Components.
| Main Steel Frame | Column | Q235, Q345 / S275/ S355 welded H section steel/ Trusse Section |
| Beam | Q235, Q345 / S275/ S355 welded H section steel/ Trusse Section | |
| Secondary Frame | Purlin | Q235/Q345/ G450 C and Z purlin |
| Knee brace | Q235B Angle Steel | |
| Tie Rod | Q235B Circular Steel Pipe | |
| Brace | Q235B Round Bar | |
| Vertical and Horizontal Support | Q235B Angle Steel, Round Bar or Steel Pipe | |
| Maintenance system | Roof Panel | EPS Sandwich Panel / Glass Fiber Sandwich Panel /Rock Wool Sandwich Panel / Pu Sandwich Panel /Steel Sheet |
| Wall Panel | Sandwich Panel / Corrugated Steel Sheet | |
| Accessories | Window | Aluminium Alloy Window / PVC Window / Sandwich Panel Window |
| Door | Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door | |
| Rainspout | PVC | |
| Live load on Roof | In 120kg/Sq.m (Color steel panel surrounded) | |
| Wind Resistance Grade | 12 Grades | |
| Earthquake-resistance | 8 Grades | |
| Structure Usage | Up to 50 years | |
| Finishing Options | Vast array of colors and textures available | |
| Paint Options | Zinc rich epoxy painting, one primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.) Or Galvanized. | |
Please contact with us, if you are planing to set up such buildings.
| Compay Name: | ||||||||
| Client | Tel/Fax: | E-mail: | ||||||
| Building Basic Information | ||||||||
| Project: | Project No.: | |||||||
| Location | Building Usage | Total area | ||||||
| Length (m) | Width (m) | Eave Height (m) | ||||||
| Roof material | ||||||||
| Wall material | ||||||||
| Design Load and Meteorological Conditions | ||||||||
| Wind load (kn/m2) | Wind speed (m/sec) | Snow load (kn/m2) | ||||||
| Rainfall Capacity | Earthquake Grade | |||||||
| Please fill out the below information if your building has the mezzanine | ||||||||
| Height of Mezzanine(m) | Usage of mezzanine | |||||||
| Live load on mezzanine(kn/m2) | ||||||||
| Please fill out the below information if your building has the crane | ||||||||
| Capacity (t) | Span (m) | Quantity | ||||||
| Hoisting height (m) | Other information about crane | |||||||
|
