300mm Bronze Pipes Horizontal Continuous Casting Machine 0.3 Tons Melting Furnace

Categories Copper Continuous Casting Machine
Brand Name: Jingjie
Model Number: GVT
Place of Origin: WUXI
MOQ: 1set
Price: negotiation
Payment Terms: T/T or L/C
Supply Ability: 10sets per month
Delivery Time: 30 working days after received your payment
Packaging Details: Packed in wooden case for outer packing
Product material: Bronze
Product: Pipe
Product diameters: Φ(28--300)mm
Type: Horizontal
Thickness: 4--80 mm
Furnace type: Melting and holding high and low combined furnace
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
  • Submit Buying Request
    • Product Details
    • Company Profile

    300mm Bronze Pipes Horizontal Continuous Casting Machine 0.3 Tons Melting Furnace


    300mm Bronze Pipes Horizontal Continuous Casting Machine 0.3 Tons Melting Furnace​


    Ⅰ. Specifications:

    1. Types of casting specifications

    * Bronze


    1.1 Hollow billets (tube-shaped)

    a. Range of outer diameter Φ(28--300)mm

    b. Range of wall thickness 4--80 mm

    c. Number of production lines

    1-- 8 lines( according to section conditions)



    Ⅲ. Equipment Components List of Horizontal Continuous Casting Production line for Rod-Wire

    No.Equipment Name and Spec.UnitQuantityRemarks
    1
    2Melting furnaceset1Including melting groove, coil, waer jacket and iron core.
    3Chuteset2One in-use and one standby
    4Holding furnaceset1Including melting groove, coil, water jacket, iron core, vertical temperature measurement device (specially-made), thermocouple (containing platinum and rhodium) and protection tube.
    5Molten steel storage ladle and chuteset1For transferring material into the mold after sintering in holding furnace.
    6mold system (Ф30-200)set2Including graphite mold
    7Dragger (5KW)set1
    8Synchronized auto-tracking sawing machineset1
    9Material stock platformset1Chain drive, length of 5M
    10Header tankset1
    11Traction carrier rollerSet1
    12Cooling water distributorset1Including cooling water for transformer, reactor, coil of electric furnace, water jacket, water-cooling cable, and mold (primary and secondary cooling).
    13Hydraulic systemset2

    Including hydraulic station and cylinder

    (The hydraulic components produced by YUCI YUKEN HYDRAULICS CO., LTD. are adopted)

    14Electric-control operation system of electric furnaceset1Including the control cabinet for melting furnace and holding furnace (Siemens is chosen for main electrical elements).
    15Process control operation systemset1For control of servo motor and process, synchronized auto-tracking sawing machine, and control of material stock platform.

    FAQ


    Q1: What is your main brand for the electrical and mechanical parts?
    A: China famous brand


    Q2: could you please arrange the installation and commissioning ?
    A: Yes , we could and the buyer pay the charge


    Q3: could you arrange the production education?
    A: Yes , we could and the buyer pay the charge


    Q4: could you do the design for the whole plant
    A: Yes , we can
